1. SPECIFICATIONS

DIGITAL DISPLAY
DIMENSIONAL READOUT
GAGING RANGE
DIGITAL RESOLUTION
GAGING MODE CONTROL
THICKNESS/VELOCITY SWITCH
PULSER
Risetime
Selectable Amplitude
Selectable Rep Rate
RECEIVER
Manual Gain Mode
AGC Mode
Reject
Bandwidth
Attenuator
DAMP CONTROL
SCOPE DISPLAY
Sweep Speed
Bandwidth
Dual Trace
A-Scan Video
Sweep Delay
T-Gate
IP-Gate
IF-Gate
T-Gate Start/Stop
TAC Gate
ALARMS
OUTPUTS/INPUTS
AC POWER REQUIREMENTS
Line Input Voltages
Line Frequency
Power Consumption (Max)
OPTIONS
Single/Double Transducer Mode
Model 5000L
SIZE
WEIGHT
Manual No. OM5000
Jan X/04 Ver 1.40
Four Digit "Virtual" (LED), With 0.05 Second Update
English And Metric (Selector Switch)
English: 0.005-10"; Metric: 0.13mm To 100mm (Depending Upon Material)
English
±0.0001" On 1" Range
±0.001" On 10" Range
Sets Mode For Contact, Delay Line Or Immersion Transducers
Selects Digital Display Of Thickness Or Velocity
5 To 10 ns Into 50 Ohms, Depending On Pulser Voltage
90, 150 And 300 Volts Peak Into 50 Ohms
625, 1200, 2500 And 5000 pps
72 dB
40 dB Dynamic Range, 72 dB Gain
Variable Threshhold To Full-Scale Display
30 MHz (6 dB Down), 20 MHz (3 dB Down)
0, 10 And 20 dB Selectable
To Optimize Echo Waveshape, 15-350 Ohms
Switchable To 50 ns/Div. + Continuously Adjustable
50 MHz
A-Scan + Selectable Gate Traces (IP, IF, T or TAC)
Full RF, Positive and Negative Rectified
Delay Sync 1 us To 80 us
Thickness Gate, Adjustable Sync
0.25 To 20 us On Contact, 1.0 To 90 us On Delay And Immersion
0.1 To 8.0 us
Selects Polarity Of Echo's Leading Half-Cycle
Multi-Adjustable Time Compensated Gain:
Start Control........................0.2 To 6 us
Amplitude Control................0 To 17 dB
Slope Control.......................1 To 50 us
Three-Function, LO, HI, LO & HI
Multi-Pin Port With High-Speed Binary Output, RS-232C I/O, PortaScan Outputs, And
HI/LO Alarm; Input Of External PRF Sync; IP Sync Output; Analog Thickness Output ( 0-
5V)
Nominal 115 V - 220VAC (90-264V)
47 - 63 Hz
70 Watts
Two Transducer Connectors And Switch For Single Pulse-Echo, Dual (Pitch-Catch) And
Through Transmission Modes.
Addition Of On-Board Datalogger And Hand Command Module To Standard 4500 Model.
5.4" (138mm)H x 12.9" (327mm)W x 17.2" (438mm)D. Inclusion Of Tilt Handle Increases
W To 15.0" (380mm) And D (Fully Extended) To 20.1" (511mm).
16 Lbs. (7.3 Kg)
1
Metric
±0.001mm On 10mm Range
±0.01mm On 100mm Range
