NewTek TriCaster Mini HD-4 Manual page 53

ISO RECORDING
But that's just one recording. With TriCaster Mini's built-in IsoCorder technology, you can isolate, or ISO, up to
four different recordings simultaneously.
Start by opening the Record Configuration panel.
Notice that your Primary Recording is set for Output 1. By default, the second recording source is set for
Output 2, the third is set for CAMERA 1, and the fourth for CAMERA 2. You can change the settings for your
Primary Recording and your Secondary Sources. These include the Source, Save To destination, and file
format. Simply mouse over the appropriate field (or the gear icon for file format), click to open the drop-down
menu, then click on the desired option.
IMPORTANT: When adding secondary recording sources, it is highly recommended that no more than
two recordings be assigned to SAVE TO the same drive. If you have more than two recordings
assigned to SAVE TO the same drive, you will see a warning message in the Record Configuration
panel. Depending on your TriCaster Mini model, you may require external storage to achieve the
maximum of four simultaneous recordings. See TRICASTER MINI AND ISO RECORDING on the
following page for more details.
When you are finished, click Close in the bottom right corner of the Record Configuration panel. And, best
of all, whether TriCaster Mini is set for one, two, three or four recordings, it still only takes one click to start
recording.
TriCaster Mini Go Make Your Show Guide
Mouse over the Record button in
the top-right corner of the screen to
reveal the gear icon on the right edge
Click the gear icon to open the
Record Configuration panel
In the top left of the Secondary
Sources section, click the switch to
turn it blue (this indicates that secondary
sources are ready to be added)
In the bottom left of the
Secondary Sources section,
click the Add Source button
to add a second recording source
Repeat step 4 to add a third and
fourth recording source
52
#1
#2
#3
#4
#5
