NewTek TriCaster Mini HD-4 Manual page 42

CONFIGURING TRICASTER MINI OUTPUTS CONTINUED
1 Double-click the large Program window to open the Output Configuration panel
2
Locate the connection settings for the output you would like to change
3
Click on the Video field for the output to open the video source selection menu
4
Mouse over and click on a source to select
5
Repeat steps 3 and 4 for the Audio
6
Click Close to close the Output Configuration panel
See the Output Configuration section of the TriCaster Mini User Guide for more details.
3
2
Now, let's work with the M/E in EFFECTS mode.
TriCaster Mini Go Make Your Show Guide
4 5
41
1
6
