These next-level steps will introduce you to a section of the Live Desktop we haven't talked about yet – the
Mix Effects panel.

1) Mix Effects

When you first start a session, the Mix Effects panel is hidden. To open the Mix Effects panel:
#1
Click on the divider bar located above the switcher that is labeled MIX EFFECTS
When you click on the divider bar, a second panel appears above the video switcher that looks very similar to
the switcher itself. This is a Mix Effects panel, also known as an M/E, and it has two modes—MIX and
EFFECTS. Let's take a moment to explore the M/E to see how the most essential controls are organized in
each mode.
MIX EFFECTS PANEL – MIX MODE
1
2
The M/E tabs, which you can click through to work with any of TriCaster Mini's 4 Mix Effects panels.
1
The M/E bus, which includes two rows of buttons – row A and row B. When you click on a video
2
source, its button will light up
The transition controls, which includes the T-Bar, TAKE and AUTO buttons, and transition palette.
3
The mode selector button, which lets you alternate between MIX and EFFECT modes.
4
The Key layer toolset, which you can use to apply an overlay to the M/E.
5
blue gold
on row A and
TriCaster Mini Go Make Your Show Guide
3 4
on row B.
