MIX EFFECTS PANEL – EFFECTS MODE
1
2
The M/E tabs, which you can click through to work with any of TriCaster Mini's 4 Mix Effects panels.
1
The M/E bus, which includes two rows of buttons – row A and row B. When you click on a video
2
source, its button will light up
includes positioner controls, which are located to the left of the row A and row B 1 buttons.
The effect controls, which include the T-Bar to operate the virtual zoom and the effect preset palette.
3
The mode selector button, which lets you alternate between MIX and EFFECT modes.
4
The Key layer toolset, which you can use to apply an overlay to the M/E.
5
Let's start by working with the M/E in MIX mode.
IMPORTANT: Toggle the mode for the M/E by using the mode selector button. This is the button to the
right of the FTB button above the T-Bar. Simply click on the mode selector button to open the
drop-down menu, then click on Mix or Effect for the desired mode.
M/E – MIX MODE
In MIX mode, the M/E works almost exactly the same as the switcher, with row A serving as the Program row,
row B serving as the Preview row, and identical transition controls allowing you to mix between the two.
To start, follow these steps to set up the video switcher and M/E 1 to practice using the M/E in MIX mode.
blue
on row A and
#1
If you are live streaming, click on the Stream button
in the top-right corner to stop streaming
TriCaster Mini Go Make Your Show Guide
3
gold
on row B. In EFFECTS mode, each row also
