Special Applications

Special Application
If you use Internet applications which have non-standard connections or port numbers, you may find that they do not function correctly because they are blocked
by the XC-DPG603 firewall. In this case, you can define the application as a "Special Application" in order to make it work.
Note that the terms "Incoming" and "Outgoing" on this screen refer to traffic from the client (PC) viewpoint.
Settings - Special Applications
Select Special Application Name
This lists any special applications which are currently defined.
Select Name Item
• Ignore this list if adding a new Special Application. Enter your data in the Special Application Configuration section, and click the
"Add" button.
• To edit an existing entry select it from this list and click the "Select" button. The data for the selected application will then be
displayed in the Special Application Configuration section. Make any required changes and then click the "Update" button.
Special Application Configuration
Use this to Enable or Disable the Special Application.
Enable
Enter a descriptive name to identify this Special Application.
Name
Select the protocol used by this application when sending data to the remote server or PC.
Outgoing Protocol
For data being sent, enter the beginning and end of the range of port numbers used by the application server. If the application uses a
Outgoing Port Range
single port number, enter the range in both fields.
Select the protocol used by this application, when receiving data from the remote server or PC.
Incoming Protocol
For data being recieved, enter the beginning and end of the range of port numbers used by the application server. If the application
Incoming Port Range
uses a single port number, enter it in both fields.
Buttons
• Add – Create a new Special Application entry.
• Delete – Delete the selected entry.
• Update – Save any changes you have made to the current entry.
• Cancel – Cancel any changes you have made since the last save operation.
This shows details of all Special Applications which are currently defined.
Special Application List
Using a Special Application on your PC
Once the Special Applications screen is configured correctly, you can use the application on your PC normally. Remember that only one (1) PC can use each Special application at any time.
Also, when 1 PC is finished using a particular Special Application, there may need to be a "Time-out" period before another PC can use the same Special Application.
If an application still cannot function correctly, try using the "DMZ" feature, if possible.
25
