Advanced PPTP

Figure 9. Advanced PPTP
Settings - Advanced PPTP
Select the desired Port and click the "Select" button. The data for the selected Port will then be displayed in the WAN IP Account section.
WAN Port
WAN IP Account
• User Name – The PPTP user name (login name) assigned by your ISP.
• Password – This field is associated with the User Name above. This is assigned by your ISP and used to login to the PPTP Server.
• Verify Password – Re-enter the PPTP password assigned by your ISP.
• IP Address – Enter the IP address of the PPTP Server. (This is provided by your ISP)
• Static IP Address – If you have a fixed IP address, enter if here. Otherwise, this field should be left at 0.0.0.0.
Use the "Connect" and "Disconnect" buttons to establish or terminate a connection on this session.
Action
This displays the current connection status.
Connection Status
20
