Advanced PPPoE

The screen is required in order to use multiple
PPPoE sessions on the same WAN port.
It can also be used to manually connect or
disconnect a PPPoE session.
Settings - Advanced PPPoE
Select the desired Port and Session, then click the "Select" button. The data for the selected Port/Session will then be displayed in the
WAN Port
PPPoE Session
WAN IP Account section.
WAN IP Account
• User Name – Enter the PPPoE user name assigned by your ISP.
• Password – Enter the PPPoE password assigned by your ISP.
• Verify Password – Re-enter the PPPoE password assigned by your ISP.
• IP Address – If you have a fixed IP address, enter it here. Otherwise, this field should be left at 0.0.0.0.
• Host Name – This field is used by a Host to uniquely associate an access concentrator to a particular Host request.
Use the "Connect" and "Disconnect" buttons to establish or terminate a connection on this session.
Action
This displays the current connection status for each session.
Connection Status
Figure 8. Advanced PPPoE
19
