ASA104 Instructions Page 1
Aft (Stern)
To begin: Place the ship in the stand. Carefully
unroll and separate the sails.
Port
Starboard
Set the bowsprit: Slide the bowsprit through the
opening at the front end of the ship until it stops
at the anchor. Hold the bowsprit in place by
connecting the bowline from under the bow to the
eye on the under side of the tip of the bowsprit.
Hook the bowsprit shroud lines to the eyes on the
port and starboard sides of the hull.
Main Maststep
Main Mast Shrouds
Bow Shroud
Lines
Bow Line
Bowsprit
The Netherlands
Authentic Models BV
Ambachtsweg 37
NL-3899 AM
Zeewolde
Fore Maststep
Bowsprit
Shrouds
Mizzen
Mast Shrouds
United States
Authentic Models, Inc.
888 Garfield
P .O. Box 21710
Eugene, OR 97402
Fore (Bow)
End of
Bowsprit
Advertisement
Related Manuals for Authentic Models ASA104
Summary of Contents for Authentic Models ASA104
- Page 1 ASA104 Instructions Page 1 Main Maststep Fore Maststep Aft (Stern) Fore (Bow) End of Bowsprit Bowsprit Shrouds Mizzen Mast Shrouds Main Mast Shrouds To begin: Place the ship in the stand. Carefully unroll and separate the sails. Bow Shroud Lines...
- Page 2 ASA104 Instructions Page 2 3. Forestay line to top eye Shroud Lines 1. Hook Jib Sail block to 2nd eye Forestay 4. Attach Jib Sail running lines to Main Mast shroud eyes 2. Hook Jib Sail and Forestay line to end of...
- Page 3 ASA104 Instructions Page 3 Attach and Hoist the Main Sail: Stay between Masts Boom Main Mast Shrouds 1. Connect the hook on the end of the boom to the eye on the hardware encircling the bottom of the mast. Set the Main Mast: Place the tallest mast in the maststep in the middle of the ship.
- Page 4 Attach the hook on the end of the line to the eyehook on the port side of the maststep. The Netherlands United States Authentic Models BV Authentic Models, Inc. Ambachtsweg 37 888 Garfield NL-3899 AM P .O. Box 21710...
- Page 5 ASA104 Instructions Page 5 Connect Block Connect Hooks Traveler 5. At the stern, connect #1 block to the underside 4. Connect hooks from the two blocks to the first of the boom. The #2 block connects to the stern. and second eyes on the aft side of the mast.
- Page 6 ASA104 Instructions Page 6 Fore sail: Repeat steps 1-4 the same as the Main Mast. Twist open the mast rings. Place around the mast pole. The stern end of the fore sail boom is connected by a block and tackle. Hook #1 connects to the eye on the starboard side of the main mast’s...
