Removing a JCS 1200 Power Module

Related Topics
Figure 1 on page 1 shows how to remove and install a power module.
Figure 1: Removing and Installing a JCS 1200 Power Module
To remove a power module (see Figure 1 on page 1):
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist and
1.
connect the strap to one of the ESD points on the chassis.
Open the power module handle, using one of the following procedures:
2.
For a power module in one of the upper power module bays, push the inner
handle release to the right; then pull the handle up to the open position.
For a power module in one of the lower power module bays, push the inner
handle release to the left; then pull the handle down to the open position.
Use the handle to pull the power module out of the bay.
3.
Preventing Electrostatic Discharge Damage to the JCS 1200 Platform

Installing a JCS 1200 Power Module

JCS 1200 Power Module Description

JCS 1200 Power Module LEDs

Locating the JCS 1200 Power Module Serial Number

Removing a JCS 1200 Power Module
