Juniper JCS 1200 Replacing Instructions

Replacing a JCS 1200 DC Terminal Cover

Removing a JCS 1200 DC Terminal Cover

Installing A Jcs 1200 Dc Terminal Cover
Topics include:
Removing a JCS 1200 DC Terminal Cover on page 1
Installing a JCS 1200 DC Terminal Cover on page 1
Figure 1 on page 1 shows how to remove and install a DC terminal cover.
Figure 1: Removing and Installing a JCS 1200 DC Terminal Cover
To remove a DC terminal cover from a JCS 1200 DC platform (see
Figure 1 on page 1):
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist and
1.
connect the strap to one of the ESD points on the chassis.
Power off each Routing Engine (see Powering Off a JCS 1200 Routing Engine).
2.
Turn off the power source.
3.
NOTE: After you disconnect the JCS 1200 platform from power, wait at least 5 seconds
before you connect the JCS 1200 platform to power again.
Remove the two Phillips-head screws that attach the terminal cover to the DC
4.
power box.
Pull the terminal cover away from the JCS 1200 platform.
5.
Figure 2 on page 2 shows how to remove and install a DC terminal cover.
Replacing a JCS 1200 DC Terminal Cover
