Possible shift of the panels in the vertical direction

Shift with constant step
Frame
1/3
2/3
Variable shift
X
This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement
www.irfts.com
Assembly guide for EASY ROOF EVOLUTION L-1
Support batten
End clamp
and bracket
Middle clamp
and bracket
IRFTS
Model "L-1" 60 Cells 6" Portrait
