Assembly guide for EASY ROOF EVOLUTION L-1
EASY ROOF
EVOLUTION
BIPV mounting system
For 60 cells 6 '' PV modules - PORTRAIT
INSTALLATION INSTRUCTIONS
Applicable to frames with a marking "L-1"
Document validated by NEW TECHNICAL INVESTIGATION n° L19.4580
Complies with building integration criteria*
*Except for flat profiled slate and tile roofs, according to the thickness of the tile
The EASY ROOF system is insured provided that the modules have approvals IEC 61215 and IEC 61730
Compatibility modules : www.irfts.com
This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement
INS-IN02-17-0687 Version 1.9 du 11/09/2019
www.irfts.com
IRFTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EASY ROOF EVOLUTION L1 and is the answer not in the manual?

Questions and answers

Summary of Contents for IRFTS EASY ROOF EVOLUTION L1

  • Page 1 The EASY ROOF system is insured provided that the modules have approvals IEC 61215 and IEC 61730 Compatibility modules : www.irfts.com This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement INS-IN02-17-0687 Version 1.9 du 11/09/2019 www.irfts.com...

  • Page 2: Table Of Contents

    11.3. Maritime zone, installation in the standard area or lower edge..........23 11.4. Maritime zone, installation on the side edge or at an angle ............ 24 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 3 Annex 9 Metal flashings to be tailor made ..................107-109 Annex 10 Assembly instructions for UK with battens 50 x 25 mm ............110 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 4: User Advice Sheet: Use, Maintenance And Repairs

    6. Reconnect the photovoltaic field by closing the DC switch/breaker (except if there are micro-inverters), then the AC circuit breaker. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 5: Parts List

    Dimensions of this bottom flashing batten can vary according to the roof slope , see table p. 26. For installation at the gutter. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 6: Parts Representation

    Assembly guide for EASY ROOF EVOLUTION L-1 Parts representation 1.3) Top flashing included in the frame Optional parts This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 7: Easy Roof Evoluton With Glazing Stops And Deflectors

    These three components are delivered separately Pre-assemble the deflector before starting work as shown This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 8 • Glazing stop mounting tool L-1: Tool to ensure that the brackets are installed vertically See Assembly Annexe 6 - page 75 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 9: Easy Roof Evolution On Slate Roofs With Metal Flashing

    Metal flashing is either made to order or included See Diagram and Assembly Annexe 9 - page 107 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 10: Part Markings

    We impose the installation of a roofing felt / roofing underlay before the installation of the system of integration EASY-ROOF. This roofing felt/roofing underlay must comply with regulation This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 11: Use Of Different Flashing According To The Configuration Of The Photovoltaic Field

    FRAME FRAME FRAME FRAME FRAME Roof window FRAME FRAME FRAME FRAME FRAME This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 12: Possible Shift Of The Panels In The Vertical Direction

    End clamp Support batten and bracket Frame Middle clamp and bracket Variable shift This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 13: Parts To Be Prepared Before Assembly Of The Kit

    Module Width ≤ 985 986 ≤ Module Width ≤ 994 995 ≤ Module Width ≤ 1001 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 14: Grounding Preparation For The Pv Modules

    Possibility 2 one earthing part on every module This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 15: Dimension Of The Pv Field

    25 mm MINI NOTA : see lateral edge metal sheet drawing page 63 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 16 11898 12018 Ex : (1655 x (3-1) ) + 1614+114 = 5038 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 17 NOTA : see lateral edge metal sheet drawing page 63 * Reference synopsis This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 18 80 mm MAXI. (See annex 3 p. 65) Ex : (1655 x (3-1) ) + 1614+342 = 5266 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 19: Technical Definition Of The Easy Roof Frame Installation And Sizing

    To become an EASY ROOF system installer you must be a professional with roofing and electricity expertise corresponding to the French designations QUALIPV BAT and ELEC. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 20 • For an installation with metal flashing see document N° « INS-IN02-160614 Easy Roof Evolution metal flashings for L-1 and O-1 vers.1.0 » This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 21: Normal Zone, Installation In The Standard Area Or Lower Edge

    (2) : Wingteks 6,3 x 70 ( Référence Etanco : 288 283 ou 288 889 ). (3) : The support battens are fixed to the truss or the rafters This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 22: Normal Zone, Installation On The Side Edge Or At An Angle

    (2) : Wingteks 6,3 x 70 ( Reference Etanco : 288 283 or 288 889 ). (3) : Support bettens fixed on rafters. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 23: Maritime Zone, Installation In The Standard Area Or Lower Edge

    (2) : Wingteks 6,3 x 70 ( Reference Etanco : 288 283 or 288 889 ). (3) : Support bettens fixed on rafters. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 24: Maritime Zone, Installation On The Side Edge Or At An Angle

    (2) : Wingteks 6,3 x 70 ( Reference Etanco : 288 283 or 288 889 ). (3) : Support bettens fixed on rafters. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 25: Instruction For The Assembly Of The Easy-Roof System

    2°) Position the batten (F) in order to have the top of the bottom flashing batten (H) flush with the water flow of the tile, eventually slightly higher (a few millimeters). * Reference nomenclature This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 26: Installation Of The Bottom Flashing Support Batten And The Reference Support Batten

    Reverse slope FORBIDDEN 0° * Reference nomenclature This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 27: Installation Of The Bottom Flashing

    * Reference nomenclature This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 28: Positioning Of The Flooring At The Gutter/Eave

    The dimension of positioning must be redefined, see page 29. Reverse slope FORBIDDEN 0° This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 29: Support Batten Position For Installation At The Gutter

    Reference support batten(d)* X (mm)= 435(mm) + M * Reference synopsis This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 30 The length of the metal sheet can be variable. If it is needed to use several metal sheets, those will have imperatively to overlap of 100 mm MINI. Metal sheet in transparency This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 31 Set up and fasten the bottom metal sheet all over the width of the PV field. Fasten only the top part of the bottom metal sheet. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 32 MUST REMOVE SCREWS BEFORE THE MOUNTING OF THE PV MODULES. * Reference nomenclature This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 33: Installation Of The Bottom Metal Sheet

    250 mm 250 mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 34: Flooring Installation For All Pv Installation

    (view with fictitious frames) (Left side of PV field) (Right side of PV field) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 35: Flooring For An Assembly With 4 Fixings Per Module

    Dimension E ATTENTION: check module’s compatibility ANNEX 6 page 72 on WWW.IRFTS.COM This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 36: Flooring For An Assembly With 6 Fixings Per Module

    Dimension E ATTENTION: check module’s compatibility ANNEX 6 page 72 on WWW.IRFTS.COM This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 37 450 ±100 mm Reference support (view without the tiles batten) batten This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 38: Installation Of Leaning Batten

    (view without the rafters and tiles batten) (view without the rafters and ltiles batten) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 39: Installation Of The Easy Roof System

    EASY ROOF system. Refer to this document to ensure that the installation is compliant. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 40 MUST REMOVE SCREWS BEFORE THE MOUNTING OF THE PV MODULES. * Reference nomenclature This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 41 37. Reference support batten (d)* * Reference nomenclature This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 42 PV module. Carry out this connection each second modules for each line of module. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 43 4°) Place two other mounting tool (13) on the two top frames as shown on the drawing. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 44 THE MOUNTING TOLL (13) COULD BE MOVED ONLY IF THE 4 (OR 6) MIDDLE BRACKETS ARE MOUNTED. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 45: Installation Of The Bottom Metal Sheet

    DO NOT PUT IN PLACES THE END BRACKET ON THE SYSTEM, THIS OPERATION WILL BE CARRIED OUT LATER AFTER THE POSE OF THE SIDE FLASHING. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 46: Installation And Fixing Of The Left Flashing

    Play of 3 mm d°) Optional : Clip the frieze support at the top of the last flashing. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 47 8°) If there is no batten under the flashings overlap, add a batten under the overlap. 9°) Fix all left flashings by applying instructions 6.7 and 8. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 48: Installation And Fixing Of The Right Flashing

    3 mm set d°) Optional : Clip the frieze support at the top of the last flashing. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 49 7°) If there is no batten under the flashings overlap, add a batten under the overlap. 8°) Fix all right flashings by applying instructions 5.6 and 7. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 50: Installation And Fixing Of The Support Frames And Brackets On The Edge Of The Field

    THE USE OF A MOUNTING TOOL IS MANDATORY FOR THE INSTALLATION OF THE END BRACKET ON THE LEFT SIDE OF THE PV FIELD. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 51: Installation Of The Photovoltaic Panels

    EASY ROOF EVOLUTION system). Moreover they must not touch nor interfere with the breather membrane situated underneath. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 52 (Local Cut on PV module) Tightening torque 8.8 Nm 6°) Place all the middle bracket on the PV field This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 53 PV module. Tightening torque 8.8 Nm (End clamp) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 54: Grounding

    2°) Make sure then that connection between the PV module and the bracket(5) is less than 2 Ohms. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 55: Put Back The Tiles

    It is imperative that the dimension D does not exceed 40 mm MAXIMUM Dimension D Marking “Limits tile” This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 56: Annex 1 Pyramid Installation

    A°) Flashing installation in "L" left or right 1°) Pull out the removable part at the top corner of the frame. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 57 3°) Cut the lower flashing in order to overlap the frame 150mm Minimum. 150 mm MINI 150 mm MINI This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 58 B°) Flashing installation in "T" left or right 1°) Pull out the removable part at the bottom corner of the frame. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 59 4°) Place the batten (K) at 200m from the frame (space needed for the flashing) 200 mm 200 mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 60 6°) Assemble and place the flashing as describe in the general datasheet page 46 to 49. 7°) Cut the exceeding part of the flashing in order to align with the bottom of the frame. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 61 10°) Place the bottom flashing as describe in the general datasheet page 27, respect the Minimum overlap. 11°) Align the bottom flashing with the last tile. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 62 B°) Flashing installation in "T" left or right 12°) Put the superior frame and fix the other element as describe in the general datasheet. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...

  • Page 63: Annex 2 Lateral Edge Installation

    (Cross section) (Cross section) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 64: Annex 3 Tile's Alignment Over The Top Flashing

    14. Dimension "R" 70 mm MAXI Move up the PV field This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 65 2°) Make sure the tiles or a watertight strip overlap the top of the frame with 150mm minimum. 150 mm MINI Marquage "Limite tuile" This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 66: Annex 4 Compatibility Module

    X ≤ 31 mm X > 31 mm Play 3 mm Junction box Junction box This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 67 Frame’s point ≤ 31 mm Junction box "c"= 46 mini (local cut view) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 68: Annex 5 Connection Of The Pv Cables And Grounding

    • Wire the ground every 2 brackets. • Connect the + from the inverter to the – of the first module. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 69 • Run the – and the ground along these cables in order not do a loop. • Go to the upper line. • Connect the last module. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 70 • Wire the ground every 2 brackets. • Connect the + from the inverter to the – of the first module. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 71 • Run the – and the ground along these cables in order not do a loop. • Go to the upper line. • Connect the last module. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 72 • Connect the + from the inverter to the – of the first frame module. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 73 • Go to the upper line. • Connect the last module of the row to the left Middle bracket This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 74 Annex n° 5 Connection of the PV cables and grounding • Connect the last module. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 75: Annex 6 Glazing Stops And Deflector Assembly

    1664 1704 time as the PV modules. 1665 1705 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 76 1705 1715 Vertical pitch WARNING: check compatibility page 75 or on www.irfts.com This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 77 4 BRACKET ASSEMBLY 6 BRACKET ASSEMBLY = Graduations on the tools This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 78 Proceed in this manner for all the lower single brackets of each frame to the left and to the right of the PV field This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 79 Screw the upper double bracket in place central ones for 6 bracket assembly) for each frame (see page 78) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 80 Put all the lower single brackets in place (and central e) Screw the upper single bracket in place for 6 brackets) for each frame (see page 78) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 81 GLAZING STOPS HAVE BEEN INSTALLED AND CLAMPED (for clamping see page 82) 19 mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 82 Adjust the height of the side single glazing stop support screws so that they are flush with the top of the PV module PV module This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 83 Tilt them so as to be able to insert the clamping nut under the deflector Blanking covers see page 8 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1”...
  • Page 84 9. Blanking cover assembly c) Tighten the screw to flatten the foam and to keep it in place This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

  • Page 85: Annex 7 Side Border Strip Option

    (Bottom of the PV field) (Bottom of the PV field) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 86: Annex 8 Slate Roofs - Metal Flashing

      Soakers (B-12+B-2) (B-12+B-3) Metal Zinc flashings with  standing seals This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 87: A Slate On Easy Roof Evolution Flashings

    Annex n° 8 A. Slate on EASY ROOF EVOLUTION flashings For Slate width : B≥140mm minimum This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 88: Pv Field Bottom

    A-1 PV field bottom (Bottom flashing) A-2 Side flashings 100 mm MINI 4 MINI This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 89: Side Flashings

    A. Slate on EASY ROOF EVOLUTION flashings A-2 Side flashings Authorized drilling area This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 90: Side Flashings

    Annex n° 8 A. Slate on EASY ROOF EVOLUTION flashings A-2 Side flashings This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 91 (x NB) Overlay multiple slates (x N) NB slate(s) = same level (height) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 92: Pv Field Top

    A. Slate on EASY ROOF EVOLUTION flashings A-3 PV Field top 975 mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 93 A. Slate on EASY ROOF EVOLUTION flashings A-3 PV Field top NB slate(s) see page 91 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 94: Continuous Flashing

    B. Metal flashings to be tailor made B-1 Side flashings B-11 Continuous flashing This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 95 B. Metal flashings to be tailor made B-1 Side flashings B-12 Continuous flashing This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 96 B. Metal flashings to be tailor made B-1 Side flashings B-12 Soakers Left Right This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 97 (x NB) Overlay multiple slates (x N) N slate(s) = same level (height) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 98 B. Metal flashings to be tailor made B-2 PV Field top / Slate roofs 975 mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 99 B-2 PV Field top / Slate roofs NB slate(s) see page 97 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 100 B. Metal flashings to be tailor made B-3 Field PV top / Metal flashings 200 mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 101 B-3 Field PV top / Metal flashings 200mm MINI Butyl seal 10mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 102 B. Metal flashings to be tailor made B-3 Field PV top / Metal flashings Left Right Butyl seal This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 103 Annex n° 8 C. Zinc flashing with standing seams C-1 Side flashings 200 mm This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 104 Standing joints to be defined according to the roof X depending on the construction site (40 mm MINI) Side flashings (symmetrical right and left Side flashings) This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...
  • Page 105 C. Zinc flashings with standing seals C-2 Field PV top (opening) (View A-A) 500 mm Top flashing This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 106 No contact of the sheet on the vertical frame wall 10 mm Top flashing (View B-B) Top flashing This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 107: Annex 9 Metal Flashings To Be Tailor Made

    The overlap between two metal sheets is made by opening the fold in the lower sheet with pliers Side flashing PRT0P00556AA Side flashing PRT0P00692AA - 7022 This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 108 This batten will rest on a rafter on either side and will be fixed in place by two wood screws. Wood screw Countersunk wood screw Batten Flashing plate This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...
  • Page 109 Staple PU foam Easy Roof Evolution Foam Left flashing frame plate This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS Model “L-1” 60 Cells 6” Portrait...

  • Page 110: Annex 10 Assembly Instructions For Uk With Battens 50 X 25 Mm

    A035V40 (4 fixing holes). Battens 50 x 25 mm. Fix with 4 Rounded screw 6x40. This document is the property of IRFTS. It shall not be reproduced or shared with third parties without IRFTS agreement www.irfts.com IRFTS...

Table of Contents
