Summary of Contents for Ruijie Networks i-Share+ Series

  • Page 1 Ruijie Networks – Innovation Beyond Networks RG-Wlan FAQs V1.1...
  • Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

  • Page 3: Overview

     Network Engineers  Network Administrator Obtain Technical Assistance  Ruijie Networks Websites : http://www.ruijienetworks.com  Ruijie Service Portal : http://case.ruijienetworks.com Welcome to report error and give advice in any Ruijie manual to Ruijie Service Portal Related Documents  RG-Wlan FAQs V1.1...

  • Page 4: Introduction To The Index

    2 Introduction to the Index This document collects the frequently asked questions (FAQs) about minimalist networks and provides answers by category. Because the questions are not indexed, to search for a specific question, press the shortcut key Ctrl+F in the document and enter keywords of your question in the search box.

  • Page 5: Table Of Contents

    3 Contents Overview ..............................1-3 Introduction to the Index ........................2-4 Contents ..............................3-5 FAQ ................................ 4-6 i-Share+ ........................... 4-6 WIDS Features ........................4-7 Wireless Environment......................4-10 BYOD ............................. 4-12 Authentication ........................4-12 Rogue AP ..........................4-14 Typical Case .......................... 4-16...

  • Page 6: Faq

    4 FAQ 4.1 i-Share+ Q1: Precautions for deployment The product installation packages of the master AP and mini AP are not independently released but are released together as a rack package. The rack package upgrade mode is similar to that of the common AP that is, released by the AC. The master AP decompresses the version files and the mini AP is upgrade independently.

  • Page 7: Wids Features

    The versions of the master AP and the mini AP are inconsistent. As a result, the configurations cannot be normally delivered to the mini AP. Solution: Upgrade the i-Share+ AP to the recommended version. When the i-Share+ version is upgraded, the software versions of the master AP and the mini AP are automatically synchronized.
  • Page 8 certain STAs can process the contain packets sent from the non-associated bssid, packet loss or offline state may occur. Therefore, exercise caution when you use this function. Maximum number of contains By default, the device end can contain up to 30 rogue APs. If more than 30 rogue APs need to be contained, the maximum number of contained APs should be increased.
  • Page 9 On the root-bridge, run show dot11 ass all to check whether the RSSI is increased. Launch a throughput speed testing as adjusting the antenna direction until it reaches the best performance. If the co-frequency interference exists and the channel needs to be changed, use the 802.11na channels 149, 153, 157, and 161.

  • Page 10: Wireless Environment

    root#show dot11 associations all INTF-IDX ADDR AID CHAN RATE RSSI IDLE TXSEQ RXSEQ ERP STATE CAPS HTCAPS 00:1b:b1:20:3d:0e 1 300M 66 120 10 27824 0x0 0x22b Es On the same AP, the antenna placement direction and the antenna polarization direction should be on the contrary. Otherwise, the MIMO antennas mutually interference each other.
  • Page 11 bytes). Under 1 Mbit/s transmit rate, the management frames sent by the AP require 675 ms, and occupy nearly 70% of the channels. With other AP-related detection response frames, the management frames occupy nearly 80% of the channels. When the AP replies a detection response frame, the detection response frame and the Authentication frame are considered as management frames and transmitted in the same priority queue.

  • Page 12: Byod

    4.4 BYOD Q1: Can the wireless AC connect to the MAB based on a local account? Answer: Yes, you need to create local credential and the user name and password are c8e0eb75cf94 and c8e0eb75cf94 respectively. Q2: Can the wireless AC in the same SSID implement QR code authentication and then SMS authentication? Answer: No.
  • Page 13 Q4: Why do I need to shorten the anti-jitter duration to validate the MAB perception-free authentication when both the web-based authentication and MAB authentication are configured? The anti-jitter solution for the web-based authentication is conflict with the MAB perception-free authentication solution. By default, the anti-jitter duration of the web-based authentication is 5 minutes.

  • Page 14: Rogue Ap

    the IP address. To address this issue, a function is developed on the wireless device: The STA should obtains the IP address via DHCP server first then AC sends out the Radius-accounting packet. The work principles are as follows: 1. The AC enables the DHCP snooping function. This function is used to detect whether a wireless STA obtains the IP address and corresponding DHCP snooping entry should be generated on AC.
  • Page 15 According to the logs of the AP, the AP did not send and Deauth packet. Therefore, the illegal Deauth packets were not sent by this AP. According to the preceding analysis, a rogue AP may send illegal Deauth packets to the normally associated users, as shown in Figure 2.

  • Page 16: Typical Case

    By surveying the wireless environment of the field, it was found that an AP of another carrier exists close to the test point. The data indicator of this AP quickly blinked, indicating that a large amount of data was transmitted. This AP was considered as the rogue AP.
  • Page 17 WS6008(config-ac)#strict-limit response-rssi Note: The AP530-I v1.0 does not support the coverage area configuration. Q2: Switching Internal and External Antennas Enable external antennas (internal antennas are enabled by default). FAP MODE: interface Dot11radio1/0 External-antenna enable FIT MODE: ap-config xxx External-antenna enable radio 1 Enable internal antennas.
  • Page 18 Symptom: *Mar 1 14:10:50: %LINK-3-UPDOWN: Interface Dot11radio 2/0, changed state to down. *Mar 1 14:10:50: %LINEPROTO-5-UPDOWN: Line protocol on Interface Dot11radio 2/0, changed state to down. *Mar 1 14:11:03: %LINK-3-UPDOWN: Interface Dot11radio 2/0, changed state to up. *Mar 1 14:11:03: %LINEPROTO-5-UPDOWN: Line protocol on Interface Dot11radio 2/0, changed state to up. Information collection requirements: A: AC configuration, AP configuration, and AP logs B.
  • Page 19 WS6008(config)#ac-controller WS6008(config-ac)#active-bin-file xxx.bin WS6008(config-ac)#ap-image auto-upgrade View the update status. WS6008#sh ap-config updating-list Q7: Implementation of the Bonjure Protocol [Scenario Description] Apple TV------Switch------AP (iPad/iPhone is connected to the AP in wireless mode and the Bluetooth function is enabled.) [Implementation Effect] The screen of the iPad or iPhone can be projected onto Apple TV. [Support on Ruijie Products] In the Layer-2 forwarding environment, Apple TV is in the same network segment as the iPad/iPhone.
  • Page 20 apip ipv4 x.x.x.x //Configure the AP address. acip ipv4 x.x.x.x //Set the address for establishing a CAPWAP tunnel with the AC. The fit AP stores the configuration made manually by default. Even if the configuration is not saved, it still exists after the AP is restarted, and the factory defaults need to be restored.
  • Page 21 The AP restricts the 2.4G RF card to support the access of a maximum of 25 STAs and restricts the 5G RF card to support the access of a maximum of 30 STAs, so as to ensure that STAs are evenly distributed to the two RF cards of the AP. Test Result: 4-21...
  • Page 22 Use the Mythware software to test the video play, picture play, and PPT slide. The video is played smoothly, the picture play experiences a delay of about 1 second, and PPT slide switching experiences a delay of about 1 second. Disable the multicast optimization function first: The delay of about 1 second occurs in the picture play.
  • Page 23 Q13: When the SAM+ System Associates with the AC, an Exception Occurs in the dotx-MAB and Web Authentication Scenario: When the SAM+ system associates with different types of ACs, various exceptions occur, for example, a dotx-MAB authentication exception occurs, IP addresses of STAs fail to be obtained, and the status of online users cannot be updated after they go offline.
  • Page 24 Note: Other Model indicates devices from other manufacturers; for Ruijie wireless products such as the WS6008, directly select 5708. Q14: Querying the Maximum Number of APs Supported by the AC Run the show ac-c command on the AC to display the maximum number of APs supported by the AC. The AC supports a maximum of 32 APs by default (see the first line in the following figure).
  • Page 25 When one AC is connected to two APs (AP520 and AP220), the following information is displayed: AC#show version all AP(AP220-E(C))'s version: Product ID : AP220-E(C) System uptime : 6:21:55:51 Hardware version : 3.00 Software version : AP_RGOS 11.1(5)B7, Release(02231013) Patch number : NA Software number : M13105311102015...
  • Page 26 localIpAddr6 used wtp :2.0(2 normal 0 half 0 zero) remain wtp :30 normal 60 half 638 zero HW Ver :1.01 SW Ver :AC_RGOS 11.1(5)B7, Release(02231014) Mac address :5869.6c20.6fe2 Product ID :WS6108 NET ID :9876543210012345 NAS ID :5869.6c20.6fe2 Q15: Deployment of the 2nd-generation i-Share Solution Determine the deployment mode.
  • Page 27 2) The difference between the RSSIs tested by a mobile phone or a laptop at the same position can be as high as 15 dBm and the RSSIs tested by different mobile phones are different. In the site survey evaluation, the RSSI tested by a laptop should be better than -55 dB and the RSSI tested by a mobile phone should be better than -70 dB, so as to ensure basic user experience of the mobile phone.
  • Page 28 as shown in the following figure: RSSI (normal value: RSSI > 30), RATE_Down, and RATE_UP (the latter two indicate the upstream rate and downstream rate respectively). Note: The 144.5 Mbps rate indicates that the laptop works in dual-stream mode; 72.5 Mbps and lower rates indicate that the laptop works in single-stream mode, and the download performance is poorer.
  • Page 29 Ruijie(config-ap)# ishare mode double frequency single stream Scenario 2：FAT-AP Ruijie(config)#interface Dot11radio 1/0 Ruijie(dot11-wlan-config)#antenna transmit 3 Ruijie(dot11-wlan-config)#antenna receive 3 Ruijie(dot11-wlan-config)#rate-set 11n mcs-support 7 Ruijie(dot11-wlan-config)#interface Dot11radio 2/0 Ruijie(dot11-wlan-config)#radio-type 802.11a Ruijie(dot11-wlan-config)#antenna transmit 3 Ruijie(dot11-wlan-config)#antenna receive 3 Ruijie(dot11-wlan-config)#rate-set 11n mcs-support 7 Solution 3: Single-band single-stream mode (applicable to scenarios in which more rooms need to be covered and the device performance needs to be utilized) (In this mode, both radio cards work in 2.4 GHz mode, R1-2, R1-3, R2-2, and R2-3 belong to radio card 1 whereas R1-0, R1-1, R2-0, and R2-1 belong to radio card 2.
  • Page 30 Q17: AP630 Meshing No interference or obstacle exists: The bridge distance of the AP630(CD) is within 3 km in the 5.8 GHz band. The coverage distance is 250 m in the 2.4 GHz band. Performance: When the bridge distance is about 3 km, the throughput is 100 Mbps; when the bridge distance is 1-2 km, the throughput ranges from 150 Mbps to 200 Mbps;...
  • Page 31 Q19: No SSID Signal Is Detected for the Fit AP & Fat AP Prerequisite: The configuration of the fit AP or fat AP is correct and signals that have been sent can be displayed after the sh dot11 mb command is executed. The collected information is as follows: show wbs-bssm radio-status show wbs-bssm wlan-status...
  • Page 32 q (-->Enter q to exit the top command.) exit (-->Exit shell.) 8. show ap-config summary 9. show ac-config client 10. show ap running Q21: Changes Before and After the Band-select Function Is Enabled Version: AC_RGOS 11.1(5)B8, Release(03162911) The band-select function is enabled globally in earlier versions. WS6008(config)#band-select enable In version AC_RGOS 11.1(5)B8, Release(03162911), the band-select function can be enabled globally (no prompt command is available) or enabled for a WLAN in wlan-config mode.
  • Page 33 //In AP-group mode, run the exec-cmd command to change the country code. WS6008(config-group)#exec-cmd country US radio 2 Q24: Disabling APMG Information Function In fault locating, information of APMG Level 6 may affect the debug command. To prevent this problem, disable APMG Level 6 manually.
  • Page 34 2. Solution: Step 1: Access the shell process. run-system-shell Step 2: Check the size of all files in the file directory. du -h /data Step 3: Clear all buffered files in this directory. cd /data/.rootfs/tmp/coredump rm * Step 4: Check the file size in the directory after clearing. du -h /data Step 5: Exit the shell process.
