Technical Specifications Technical Specifications - Vidicode Octo Manual

8 Technical specifications
Power supply Power supply
Power supply Power supply
Mains 90~264VAC 47~63Hz max 20W
Working environment Working environment
Working environment Working environment
Temperature : 0 to 40 degrees centigrade.
Relative Humidity : 10% - 90% No condensation must.
Connections Connections
Connections Connections
Ethernet : 10/100-BASE-T with RJ-45 connector.
Telephone line : 8x/16x RJ-45 connectors,
Dimensions Dimensions
Dimensions Dimensions
(L/W/H) : 440x315x95mm
Weight Weight Weight Weight
6,5 Kg
Technical Standards Technical Technical Technical Standards Standards Standards
EU telecommunications CTR21
EU Emission
EU Immunity
Special Spec Spec Spec ial functions of line inputs (each line) ial ial functions of line inputs (each line) functions of line inputs (each line) functions of line inputs (each line)
Reception and decoding of DTMF and FSK for Caller ID and dialing
information, including all detectors needed for all variations of caller id.
Parallel voltage controlled Off-Hook detector (or serial line current
detector when using "loop through" wiring) with two voltage settings
(10Volt/20 Volt, software controlled) for starting/stopping recordings.
Ring detector to discriminate between outgoing and incoming faxes.
Line interface can go into "sniff mode" 9pik up mode) or go online
Over-voltage protection using tranzorbs protects each input channel
against lightening etc.
Mass storage and backup storage
Internal Drive (Hard Disk or SSD).
Manual Fax Server Octo | Quarto © 2008-2014 Vidicode®
EN55022 classB
EN55024 classB
61
