Summary of Contents for Billy Goat DL1302H
-
Page 2: Specifications
Briggs and Stratton Engine: Fuel Capacity 9.00qt (8.52L) Engine: Oil Capacity 1.75qt (1.66L) Operating Safely Read the safety rules outlined in the General Safety and Warranty Manual included with this Operator's Manual in your Billy Goat Debris Loader parts bag and literature billygoat.com... -
Page 3: Safety Decals
8041032 8041032 Nut (Nozzle Intake) 8165002 8165002 Your Billy Goat Debris Loader is shipped from the factory in one carton and requires some assembly. You must assemble Nut (Band Hose Boom) 8165001 8165001 the exhaust elbow, nozzle, handle loop for nozzle, hose... -
Page 4: Initial Set-Up Assembly
I.D. Item DL1302H, DL1802VE DL1402SE, DL1802V Nut (Elbow) 8165003 8165003 Bolt (Band Hose Boom) 8041013 8041013 Initial Set-Up Assembly Hardware I.D. Part Number 8172020 Initial Set-Up Assembly 8041032 8165002 1. Securely attach unit to the bed of a truck or to a trailer, so 8165001... -
Page 5: Operation
8. Install a standard 12 volt lawn and garden battery “U1” series (not included) with at least 240 cold cranking amps and a 40 amp hour rating by using battery bracket, hold down rods, washers and lock nuts. Only models DL1402SE and DL1802VE require a battery. -
Page 6: Maintenance Procedures
that the hose will not wear on only one side, further increasing its life. CAUTION Keep the hose as straight as possible and avoid sharp bends Elbow is very heavy. Do not stand directly under elbow during operation for best pick-up and to avoid clogs. Never during removal. ... -
Page 7: Charging The Battery
6. Remove impeller bolt and lock washer by using an impact 10. Tighten impeller bolt. Torque impeller bolt to 33-38 ft.lbs wrench. See Figure 9. (45-52 N.m) for DL9-18 series. Torque impeller bolt to 175-180 ft.lbs (237-244 N.m) for DL29-37 series. 11. Repeat steps 2 through 5 in reverse order. 12. -
Page 8: Periodic Maintenance
Periodic Maintenance Maintenance Operation Each Use Every 50 Hrs Every 100 Hrs Every 250 Hrs Every 300 Hrs Check engine oil Change engine oil Check air filter Clean air filter ... -
Page 9: Wiring Diagrams
Wiring Diagrams Figure 12: DL1802V Wiring Diagram Figure 10: DL1302H Wiring Diagram Figure 13: DL1802VE Wiring Diagram Figure 11: DL1402SE Wiring Diagram... -
Page 10: Troubleshooting Table
Troubleshooting Table Problem Possible Cause Solution Will not vacuum or has poor vacuum performance • Nozzle is buried in debris • Withdraw the nozzle from the debris pile • Hose or exhaust is clogged • Unclog the hose or exhaust (See Maintenance section for more details) ... - Page 11 8" x 16.5' Hose P/N 812390 (DL902HEU only) 7" x 5' Flexible Polyurethane Hose P/N 812300 Spring Axle Trailer P/N 791152 (DL29-37 series ONLY) 8" x 10' Hose P/N 811244 (DL1302H, 8" x 5' Flexible Polyurethane Hose P/N 791107 DL1302HEU) 8" x 5' Flexible Steel Hose P/N 791106 10"...
