1. ABOUT THIS GUIDE .................................................................................................................... 4
1.1 Navigation of the User's Guide ............................................................................................................. 4
2. PRODUCT OVERVIEW................................................................................................................. 4
2.1 Introduction ............................................................................................................................................ 4
2.2 Features .................................................................................................................................................. 4
2.3 Panel Layout .......................................................................................................................................... 5
2.3.1 Front Panel ........................................................................................................................................................ 5
2.3.2 Rear Panel ......................................................................................................................................................... 6
3. HARDWARE INSTALLATION ..................................................................................................... 7
3.1 Hardware Installation ........................................................................................................................... 7
3.2 Check the Installation ............................................................................................................................ 7
3.3 Set up PC ................................................................................................................................................ 7
4. EASY SETUP .................................................................................................................................. 9
4.1 Accessing Web page ............................................................................................................................... 9
4.2 Easy Setup ............................................................................................................................................ 10
4.2.1 ISP Setting ....................................................................................................................................................... 10
4.2.2 Wireless Setting& Security .............................................................................................................................. 11
5. ADVANCED SETUP .................................................................................................................... 13
5.1 Setup ..................................................................................................................................................... 13
5.1.1 WAN ................................................................................................................................................................ 13
5.1.1.1 WAN ......................................................................................................................................................... 13
5.1.1.2 Auto PVC ................................................................................................................................................. 15
5.1.1.3 ATM ......................................................................................................................................................... 15
5.1.1.4 ADSL ....................................................................................................................................................... 16
5.1.2 LAN ................................................................................................................................................................. 16
5.1.2.1 LAN ......................................................................................................................................................... 17
5.1.2.2 DHCP ....................................................................................................................................................... 17
5.1.2.3 DHCP Static ............................................................................................................................................. 18
5.1.2.4 LAN IPv6 ................................................................................................................................................. 19
5.1.3 WLAN ............................................................................................................................................................. 20
5.1.3.1 Basic ......................................................................................................................................................... 20
5.1.3.2 Security .................................................................................................................................................... 21
5.1.3.3 MBSSID ................................................................................................................................................... 21
5.1.3.4 Access Control List .................................................................................................................................. 22
5.1.3.5 Advanced Settings .................................................................................................................................... 23
5.1.3.6 WPS.......................................................................................................................................................... 24
5.1.3.7 WDS ......................................................................................................................................................... 24
5.1.3.8 Repeater.................................................................................................................................................... 25

Table of Contents

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ND300V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Toto Link ND300V2

  • Page 1: Table Of Contents

    Table of Contents 1. ABOUT THIS GUIDE ........................4 1.1 Navigation of the User’s Guide ......................4 2. PRODUCT OVERVIEW......................... 4 2.1 Introduction ............................4 2.2 Features ..............................4 2.3 Panel Layout ............................5 2.3.1 Front Panel ................................ 5 2.3.2 Rear Panel ................................. 6 3.
  • Page 2 5.2 Advanced .............................. 26 5.2.1 Route ................................26 5.2.1.1 Static Route .............................. 26 5.2.1.2 IPv6 Static Route ............................27 5.2.1.3 RIP ................................28 5.2.2 NAT ................................. 28 5.2.2.1 DMZ ................................. 28 5.2.2.2 Virtual Server ............................29 5.2.2.3 ALG ................................30 5.2.2.4 NAT Exclude IP ............................
  • Page 3 5.5.1 Update ................................51 5.5.1.1 Firmware Update ............................51 5.5.1.2 Backup/Restore ............................51 5.5.2 Password ................................52 5.5.3 Reboot ................................52 5.5.4 Time ................................. 53 5.5.5 Log .................................. 53 5.5.6 Diagnostics ..............................54 5.5.6.1 Ping ................................54 5.5.6.2 Ping6 ................................ 55 5.5.6.3 Traceroute ..............................
  • Page 4: About This Guide

    1. ABOUT THIS GUIDE Thank you very much for purchasing this Wireless N ADSL Modem Router. This guide will introduce the features of the Modem Router and tell you how to connect and setup the router. Please follow the instructions in this guide to avoid affecting the Modem Router’s performance by improper operation.
  • Page 5: Panel Layout

    2.3 Panel Layout 2.3.1 Front Panel The front panel of Modem Router consists of 9 LEDs, which is designed to indicate connection status. POWER This indicator lights blue when the router powered on, otherwise it is off. When the router powered on, this indicator keeps lighting. It is on when ADSL port is connected and blinking when there are data ADSL transmitting.
  • Page 6: Rear Panel

    2.3.2 Rear Panel The figure below shows the rear panel of Modem Router. This socket is used to connect the power adapter. DC IN WiFi This slide switch is used to turn on or turn off WiFi. ON/OFF This RJ11 ADSL port is used to connect to ADSL modem ADSL Power Turn on or turn off the router by the switch.
  • Page 7: Hardware Installation

    3. HARDWARE INSTALLATION 3.1 Hardware Installation For the first time you use this ADSL Router, wired connection is recommended to setup the router. Please follow below steps to build correct connections through provided UTP cables. Step1: Connect Modem Router’s ADSL port to external Filter’s (provided by your ISP) ADSL port.
  • Page 8 connection between your PC and the Router. Open a command prompt, and type in ping 192.168.0.1, then press Enter. If the result displayed is similar to that shown in above figure, it means that the connection between your PC and the Router has been established. If the result displayed is similar to that shown in the above figure, it means that your PC has not connected to the Router successfully.
  • Page 9: Easy Setup

    4. EASY SETUP This chapter introduces how to Easy Setup the Modem Router so that users can easily finish the settings step by step following with the guide to access Internet. 4.1 Accessing Web page Connect to the Modem Router by typing http://192.168.0.1 in the address field of Web Browser.
  • Page 10: Easy Setup

    4.2 Easy Setup Easy Setup is provided as part of the web configuration utility. Users can follow the introductions to finish the basic settings of the Modem Router step by step. Select language at first and click NEXT button. 4.2.1 ISP Setting You’re required to choose one ISP Connection Type, after configuration is finished, please click NEXT to continue the setting.
  • Page 11: Wireless Setting& Security

    Dynamic IP, Static IP and Bridge. VPI: Virtual Path Identifier, this is based on the region you are living, generally provided by ISP. VCI: Virtual Channel Identifier, this is based on the region you are living, generally provided by ISP. 4.2.2 Wireless Setting&...
  • Page 12 2. WPA/WPA2 Wi-Fi Protected Access (WPA) is the most dominating security mechanism in industry. It is separated into two categories: WPA-personal or called WPA Pre-Share Key (WPA/PSK), and WPA-Enterprise or called WPA/802.1x. WPA2 means Wi-Fi Protected Access 2, it is the current most secure method of wireless security and required for 802.11n performance.
  • Page 13: Advanced Setup

    5. ADVANCED SETUP 5.1 Setup This setup interface allows you to configure WAN, LAN and WLAN settings. 5.1.1 WAN 5.1.1.1 WAN The ADSL router provides ADSL WAN or Ethernet WAN for you to connect to Internet. Select one type accordingly and enter the parameters provided by your ISP.
  • Page 15: Auto Pvc

    5.1.1.2 Auto PVC PVC auto detecting can be setup in this page. VPI: Virtual Path Identifier, this is based on the region you are living, generally provided by ISP. VCI: Virtual Channel Identifier, this is based on the region you are living, generally provided by ISP.
  • Page 16: Adsl

    by ISP. VCI: Virtual Channel Identifier, this is based on the region you are living, generally provided by ISP. ATM QoS: Choose the ATM QoS type provided by your ISP. By default, it is UBR selected. 5.1.1.4 ADSL This interface allows you to choose some ADSL parameters that your modem router will support.
  • Page 17: Lan

    5.1.2.1 LAN IP Address: IP Address of this ADSL Router. By default, it is 192.168.0.1. You can change it as well. Subnet Mask: Subnet Mask of this ADSL Router is 255.255.255.0. Please just keep the value. 5.1.2.2 DHCP Dynamic Host Configuration Protocol. DHCP service will supply IP settings to computers which are connected to this Router and configured to obtain IP settings automatically.
  • Page 18: Dhcp Static

    IP Pool Range: enter an IP address for the DHCP server. Since the default IP address of the Modem Router is 192.168.0.1, the IP pool range is from 192.168.1.100 to 192.168.1.200. 5.1.2.3 DHCP Static...
  • Page 19: Lan Ipv6

    5.1.2.4 LAN IPv6...
  • Page 20: Wlan

    5.1.3 WLAN 5.1.3.1 Basic On this page, you could configure the parameters for Wireless LAN client that may connect to your Access Point. Band: Specifies the standards this Modem Router complies with. Generally, it is 2.4GHz (B+G+N) selected SSID: This is your wireless network name. Others can access Internet wirelessly by searching for this SSID and connecting to it.
  • Page 21: Security

    Channel Bandwidth: this is the spectral width of the radio channel. RF Output Power: you can select the output power of the wireless device. The default value is 100%. It will deliver the best performance of the device. 5.1.3.2 Security You can setup wireless security in this page.
  • Page 22: Access Control List

    5.1.3.4 Access Control List Mode: you could choose to allow or deny the following addresses entered by you. MAC Address: enter the MAC address that you want to deny or allow.
  • Page 23: Advanced Settings

    5.1.3.5 Advanced Settings Fragment Threshold: specifies the maximum size for a packet before data is fragmented into multiple packets. The range is 256-2346 bytes. Setting the Fragment Threshold too low may result in poor network performance. The use of fragment can increase the reliability of frame transmissions.
  • Page 24: Wps

    5.1.3.6 WPS WPS (Wi-Fi Protected Setup) provides easy procedure to make network connection between wireless station and wireless access point with the encryption of WPA and WPA2. 5.1.3.7 WDS WDS means Wireless Distribution System. It is a protocol for connecting two access points wirelessly.
  • Page 25: Repeater

    5.1.3.8 Repeater The Repeater methods can help you to expand the wireless coverage and allow more terminals to access Internet.
  • Page 26: Advanced

    5.2 Advanced 5.2.1 Route 5.2.1.1 Static Route This page allows you to specify that a specific target IP addresses passes through a determined gateway manually.
  • Page 27: Ipv6 Static Route

    Destination: This is the address of the network or host that you want to assign to a static route. Subnet Mask: This value determines which portion of an IP Address is the network portion, and which portion is the host portion. Metric: Enter the metric or priority of the route.
  • Page 28: Rip

    5.2.1.3 RIP RIP means Routing Information Protocol. 5.2.2 NAT 5.2.2.1 DMZ DMZ means Demilitarized Zone. It can be enabled and used as a place where services can be placed such as Web Servers, Proxy Servers and E-mail Servers such that these services can still serve the local network and are at the same time isolated from it for additional security.
  • Page 29: Virtual Server

    DMZ Host IP Address: Type in the DMZ Host IP address. 5.2.2.2 Virtual Server Virtual server is defined as a service port, and all requests from Internet to this service port will be redirected to the computer specified by the server IP. Any PC used for a virtual server must have a static or reserved IP address because its IP address may change when using DHCP function.
  • Page 30: Alg

    Protocol: The protocol used for this application, either TCP, or UDP. Local IP Address: The IP address of the PC running the service application. 5.2.2.3 ALG Application Layer Gateway consists of a security component that augments a firewall or NAT employed in a computer network. 5.2.2.4 NAT Exclude IP NAT Exclude IP page is help to exclude addresses in the configured network range from being assigned to DHCP clients on the private network.
  • Page 31: Ftp Alg Configuration

    specified network port (triggered port), automatically opens the gateway WAN-side interfaces specified port (forwarded port), and the streams will forward to the triggered ports. You can achieve some special purposes by this setting. 5.2.2.6 FTP ALG Configuration FTP ALG may use separate connections for passing control commands and for exchanging data between the client and a remote server.
  • Page 32: Nat Ip Mapping

    5.2.2.7 NAT IP Mapping NAT Mapping function is very useful for a domestic network with one wireless router and a few devices with private IP addresses. 5.2.3 QoS...
  • Page 33: Qos

    5.2.3.1 QoS QoS means Quality of Service. Deploying QoS management to guarantee that all applications receive the service levels required and sufficient bandwidth to meet performance expectations is indeed one important aspect of modern enterprise network. 5.2.3.2 Traffic Shaping For better traffic control, you can setup upstream and downstream speeds in this page.
  • Page 34: Cwmp

    5.2.4 CWMP The Modem Router offers CWMP feature. This function supports TR-069 protocol which collects information, diagnoses the devices and configures the devices automatically via ACS (Auto-Configuration Server).
  • Page 35: Port Mapping

    URL: Enter the website of ACS which is provided by your ISP. User Name: Enter the User Name to login the ACS server. Password: Enter the password to login the ACS server. Connection Request User Name: Enter the User Name that provided by the ACS server to login the Modem Router.
  • Page 36: Others

    5.2.6 Others...
  • Page 37: Bridge Setting

    5.2.6.1 Bridge Setting 802.1d Spanning Tree: STP is implemented through the exchange of bridge protocol data unit (BPDU) messages between adjacent switches. It helps to ensure a loop-free topology for any bridged Ethernet local area network. 5.2.6.2 Client Limit After enabled client limit capability, you can setup the maximum devices that are allowed to access to Internet.
  • Page 38: Others

    V6inV4 is an Internet transition mechanism for migrating from Internet Protocol version 4 (IPv4) to IPv6. 5.2.6.4 Others In this page you can enable or disable half bridge.
  • Page 39: Service

    5.3 Service 5.3.1 IGMP IGMP (Internet Group Management Protocol) is used to manage multicasting on TCP/IP networks. Some ISPs use IGMP to perform remote configuration for client devices, such as the Modem Router. 5.3.1.1 IGMP Proxy IGMP Proxy and Multicast allowed can be configured in this page.
  • Page 40: Mld

    5.3.1.2 MLD MLD (Multicast Listener Discovery), it allows the router to find out if there is an IPv6 multicast group listeners on their directly connected network segments. 5.3.2 UPnP The Universal Plug and Play (UPnP) devices can be automatically discovered by the UPnP service application on the LAN.
  • Page 41: Snmp

    5.3.3 SNMP Simple Network Management Protocol (SNMP) is an "Internet-standard protocol for managing devices on IP networks". It is used mostly in network management systems to monitor network-attached devices for conditions that warrant administrative attention. System Name/ Location: set the administrator name and physical location.
  • Page 42: Dns

    5.3.4 DNS 5.3.4.1 DNS DNS: Domain Name System. Every Internet host must have a unique IP address, also they may have a human-friendly, easy to remember name. The DNS server converts the user-friendly name into its equivalent IP address. 5.3.4.2 IPv6 DNS This page allows you to configure the DNS server IPv6 address.
  • Page 43: Ddns

    5.3.5 DDNS DDNS means Dynamic Domain Name System. The ISP often provides you with a dynamic IP address when you connect to the Internet via your ISP. It means that the public IP address assigned to your router changes each time you access the Internet. The Dynamic DNS feature lets you assign a domain name to a dynamic WAN IP address.
  • Page 44: Ftp Server

    5.3.6 FTP Server 5.4 Firewall While the broadband users demand more bandwidth for multimedia, interactive applications, or distance learning, security has been always the most concerned. The firewall of this router helps to protect your local network against attack from unauthorized access.
  • Page 45: Ip/Port Filter

    Direction: select outgoing or incoming to setup the corresponding value. Source MAC: enter the starting IP address that you want to deny or allow. Destination MAC: enter the ending IP address that you want to deny or allow. 5.4.2 IP/Port Filter 5.4.2.1 IP/Port Filter This page is used to set IP/Port filter rule.
  • Page 46: Ipv6/Port Filter

    5.4.2.2 IPv6/Port Filter This page is used to set IPv6/Port filter rule.
  • Page 47: Url Filter

    5.4.3 URL Filter This page is used to set URL filter rule. You can active this function and enter URL links that want to filter.
  • Page 48: Acl

    5.4.4 ACL ACL means Access Control List. This page is used to control the access of this Modem Router. 5.4.4.1 ACL Direction Select: Set the ACL rule for LAN or WAN. Secure IP Address: Enter the secure IP address range that you allow to access this Modem Router.
  • Page 49: Ipv6 Acl

    5.4.4.2 IPv6 ACL 5.4.5 DoS The DoS Prevention functionality helps you to detect and mitigate the DoS attack. The attacks are usually categorized into two types, the flooding-type attacks and the vulnerability attacks. The flooding-type attacks will attempt to exhaust all your system’s resource while the vulnerability attacks will try to paralyze the system by offending the vulnerabilities of the protocol or operation system.
  • Page 50: Maintenance

    5.5 Maintenance This section includes settings for Administration, Time Zone, Firmware, Log and...
  • Page 51: Update

    Diagnostics. 5.5.1 Update 5.5.1.1 Firmware Update New version of firmware will be released to improve the various efficiency or to fix some bugs. Following the steps show below so as to realize upgrading. This page allows you to upgrade the Access Point firmware to new version. Please note: DO NOT power off the device during the upload because it may crash the system.
  • Page 52: Password

    which was saved previously. Besides, you could reset the current configuration to factory default. 5.5.2 Password In this section you can modify the administrator password to protect your device from unauthorized configuration. The default administrator’s password should be changed on the very first system setup.
  • Page 53: Time

    5.5.4 Time You can set the time server and time zone for your wireless Router system time. You can specify the device’s time zone according to GMT (Greenwich Mean Time) or copy computer time as the current time only by clicking the Copy Computer Time button. Time Zone Select: Select the Time Zone where the router is located.
  • Page 54: Diagnostics

    5.5.6 Diagnostics This section is useful for testing unless you know what effect the configuration will have on your wireless router. 5.5.6.1 Ping...
  • Page 55: Ping6

    5.5.6.2 Ping6 5.5.6.3 Traceroute Traceroute is a network debugging utility that attempts to trace the path a packet takes through the network. 5.5.6.4 Traceroute6 Traceroute6 is an IPv6 varaint of the IPv4 traceroute tool, a computer network tool used to determine the route taken by packets across an IP network.
  • Page 56: Adsl Diagnostic

    5.5.6.6 ADSL Diagnostic Click Start button to enable diagnose function and then you can see ADSL status in this page.
  • Page 57: Diagnostic Test

    5.5.6.7 Diagnostic Test It is useful for checking connection status. Please press Run Diagnostic Test button.
