Component Parts Of Vehicle - Faller Car System Digital 3.0 Vehicle Instruction Manual

General view of product

Component parts of vehicle

4
1
6
5
2
3
12
10
8
EN
9
11
7
Fig. 1: Component parts of a Car System Digital vehicle
1. Steering axle with slider
2. Motor with gear
3. Magnetic field sensor
4. On/Off switch
5. Charging socket with pin assignment
6. Loudspeaker
7. Headlights
8. Rear lights and stop lights
9. Front warning lights (only on vehicles with special signalling equipment)
10. Warning beacons (only on vehicles with special signalling equipment)
11. Turn signal/Flashlight turn signal
12. Ultrasonic capsule
