- Page 1 INSTALLATION MANUAL & USER’S GUIDE 483 N. FRONTAGE RD. NIPOMO, CA 93444 PHONE 805.929.3545...
- Page 2 (for permanent installations) and a 10-foot guitar cable (for temporary installations). The M1 will t guitars with soundholes larger than 3.55” that are centered beneath the strings. Ensure that this product will t the guitar properly before making any alterations to the instrument.
- Page 3 3.5” in diameter. Also, a few guitars have o -center soundholes that will not allow the pole pieces to be directly under the strings. If you have one of these, plug in the M1 using the 10-foot cord, and see how well it works before you alter your guitar.
- Page 4 Tighten the screws snugly, but don’t overdo it -- this can damage the pickup or guitar nish. If you are concerned about the possibility of the M1 Active damaging the instrument’s nish, consider applying thin cork pads (not included) between the...
- Page 5 High impedance devices such as active direct boxes will capture all of the M1’s nuances. Our Para D.I. partners well with the M1 due to its high impedance, clean gain and EQ capability.
- Page 6 Do not force the pole pieces any further! This could damage the pickup permanently. 4.3. Mixing with other sources: The M1 is intended to provide a complete sound from a single passive pickup. However, you may still want to pair it with another transducer.
