Lascal BuggyBoard-Maxi Owner's Manual page 6

7
Alt. A
8
7. Positioning the cotter pins.
Measure the distance between the middle of
each of the connectors.
Deciding the cotter pin direction.
If the measured distance is between:
• 31-43 cm (12.4-17.2 in.)
• 43-54 cm (17.2-21.6 in.)
B 8. Choosing the right cotter pin hole.
A
There are three holes in each arm. To choo -
se the hole that best suits your buggy, posi-
1
tion the BuggyBoard™ as close as possible to
2
the back of your buggy, however do make
3
sure that your child can stand comfortably.
Screw the cotter pin into the chosen cotter pin
hole, tighten with a coin. If the arms are too
short to fit to your buggy, use the 'Extender
Kit', see Fig 13.
- 5 -
Alt. A below.
Alt. B below.
Alt. B
