  • Page 1 O P E R A T I N G I N S T R U C T I O N S T4000 Multi Transponder safety switches...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 3: Table Of Contents

    Troubleshooting................. 31 Safety......................LED status indicators................System status................... 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 4 List of figures..................44 List of tables..................45 O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 5: About This Document

    The following information is available via the Internet: 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 6: Symbols And Document Conventions

    In practice, there are different dangerous states, such as: • Machine movements • Electrical parts O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 7 Visible and invisible beam • A combination of multiple hazards 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 8: Safety Information

    The safety switch must be configured, mounted, connected, commissioned, and ser‐ viced by qualified safety personnel only. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 9 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 10: Product Description

    The T4000 Multi transponder safety switch is uniquely coded: An actuator must be taught in at the connected sensors during commissioning. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 11: Product Characteristics

    The T4000 Multi transponder safety switch has a reset function. The function can be taught in during commissioning. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 12 If the contactors do not drop out, the T4000 Multi transponder safety switch will pre‐ vent the protective device from being reset. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 13: Project Planning

    If the mounting location is not specified by the machine documentation, it must be cho‐ sen carefully, see "Mounting", page 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 14: Integration Into The Electrical Control

    Make sure that downstream contactors are monitored (external device monitoring, EDM). O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 15 The T4000 Multi transponder safety switch has an external device monitoring function. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 16 O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 17 Connection example with two sensors, including manual reset and external device monitoring (EDM) Figure 3: Connection example T4000-1RCA02 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 18: Thorough Check Concept

    "Thorough check", page O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 19 Thorough check of the safety switch for signs of misuse or manipulation 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 20: Mounting

    If the mounting location is not specified by the machine documentation, it must be cho‐ sen carefully. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 21 (e.g. ventilator) between the evaluation units, observe a dis‐ tance of 10 mm for heat dissipation. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 22 50 mm must be adhered to in order to avoid mutual interference. Figure 5: Minimum distance when several safety switches are mounted O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 23: Electrical Installation

    Only copper with a temperature resistance of at least 75 °C must be used as the ■ cable material. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 24: Sensor Connection

    Protect the voltage supply before terminal UB with a fuse that has a maximum rat‐ ing of 8 A. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 25 External device monitoring (EDM) connection Reset pushbutton connection 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 26: Block Diagram

    Anschluss Rücksetztaster Figure 8: Block diagram with two sensors O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 27 Anschluss Rücksetztaster Figure 9: Block diagram with four sensors 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 28: Commissioning

    Jumper terminals J1 and J2 with a shorting jumper. Set the hardware configuration using the DIP switches on the evaluation unit. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 29 The DIP switch setting and the connected configuration do not match. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 30: Thorough Check

    O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 31: Troubleshooting

    In the event of a fault, the evaluation unit can be reset to operational status by inter‐ rupting the voltage supply (approx. 10 seconds). 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 32: System Status

    Displays other than those described here indicate an internal device fault. In this case, please contact your SICK subsidiary. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 33: Maintenance

    The LEDs OUT and ERROR are off. ° Close all guards. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 34: Functional Test (Self-Test)

    In the case of operation with manual reset, the reset pushbutton must be pressed again to start the system. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 35: Decommissioning

    SICK will be glad to help you dispose of these devices on request. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 36: Technical Data

    Operation permitted only with UL Class 2 voltage supply cULus or equivalent measures O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 37 Operation with manual reset Actuation time of reset button 250 ms 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 38: Sensors T4000-Dna

    Minimum and maximum values, see Technical data. O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 39: T4000-1Kba Actuator

    The dwell time is the time in which the actuator must be located inside or outside the response range. 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 40: Dimensional Drawings

    Figure 12: Dimensional drawing of sensor T4000-DNA..P (mm) Sensing face O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 41 Figure 14: Dimensional drawing of actuator T4000-1KBA (mm) Sensing face 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 42: Ordering Information

    Connecting cable 25 m, angled male connec‐ 6034394 Safety screws M4×14, 20 pcs 5309170 O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 43: Annex

    130, 50968 Köln EC type examination: • ET19020 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 44: List Of Figures

    13. Dimensional drawing of sensor T4000-DNAC (mm)..........41 14. Dimensional drawing of actuator T4000-1KBA (mm)..........41 O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK...
  • Page 45: List Of Tables

    10. Device part numbers....................42 11. Accessories part numbers..................42 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
  • Page 46 LIST OF TABLES O P E R A T I N G I N S T R U C T I O N S | T4000 Multi 8022726/2019-05-07 | SICK Subject to change without notice...
  • Page 47 LIST OF TABLES 8022726/2019-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | T4000 Multi Subject to change without notice...
