- Page 1 Documentation A06, A08, A10 Each serial number is unique to that specifi c conveyor and provides mk North America with complete order details. The conveyor serial number is located on the frame or motor mount at the drive end of the conveyor.
-
Page 2: Table Of Contents
Wear Items & Maintenance Conveyor Stands/Supports Conveyor Chain Maintenance Adjusting Slip Clutch Troubleshooting Guide Notes & Contact Information 11.2 Contacting mk North America, Inc. mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 2... -
Page 3: General Information
The importance of reading your manual Inside this manual you will fi nd the instructions on how to set up and maintain your mk conveyor properly, as well as maximize its performance. Please take the time to read this manual and familiarize yourself with these set up and maintenance instructions. -
Page 4: Decoding Your Serial Number
DWG# field is blank it is not a cause for concern. SO#: This is the shop order number in which this unit was built. This is an mk North America, Inc. internal number. This number is also referenced on any related invoices, etc. -
Page 5: Conveyor Description
Gearmotor Mount/Drive Assembly - serial number plate mounted here Gearmotor Flat Top Chain Side Rails Support Stand Horizontal Wheel Bend Vertical Bend mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 5... -
Page 6: Warranty Information
Warranty mk North America, Inc. (MKNA) offers a COMPLETE ONE YEAR WARRANTY from the date of delivery, to the original purchaser of the MKNA equipment (CUSTOMER), to be free from defects in material and workmanship; under normal use and with proper installation, maintenance and cleaning. -
Page 7: Safety Requirements
SAFETY REQUIREMENTS Warnings - Safety Guidelines READ AND UNDERSTAND ALL OF THESE WARNINGS PRIOR TO OPERATING EQUIPMENT. mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 7... - Page 8 Technical Documentation SAFETY REQUIREMENTS (CONT.) mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 8...
-
Page 9: Wear Items & Maintenance
• All parts which contact the product should be cleaned weekly (example: chain). • Chains require little special care. • Remove heavy grease coatings with ethyl alcohol. mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com... - Page 10 Technical Documentation WEAR ITEMS & MAINTENANCE (CONT.) Drive, Direct Drive (Cont.) NOTE: Not all items shown in all views for clarity. mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 10...
- Page 11 * LEGEND: Inspect, Replace, Tension, Clean, Lubricate (grease). NOTE: For adjusting the chain tensioning, please see the related section for details. When cleaning the chain, avoid any harsh chemicals or detergents. mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com...
- Page 12 If wear visible I, C 500 Hours (Max. 3 Months) Wear Strip If wear visible * LEGEND: Inspect, Replace, Tension, Clean, Lubricate (grease). mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 12...
- Page 13 I, C, T 500 Hours (Max. 3 Months) Conveyor Chain If wear visible * LEGEND: Inspect, Replace, Tension, Clean, Lubricate (grease). mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 13...
-
Page 14: Conveyor Stands/Supports
• Carefully install all connections and check that they are tight. • To ensure against tipping, the stands or base plates of the mk product must be anchored to the floor. mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com... - Page 15 CONVEYOR STANDS/SUPPORTS (CONT.) Stands/Supports Supplied by mk North America, Inc. Before securing to the fl oor, fi rst level the mk product using the fl oor pads (if purchased). Use shims for preliminary alignment, if necessary. Floor Mounting Stands, which are furnished with fl oor plates or fl oor mounting brackets,...
-
Page 16: Conveyor Chain Maintenance
Pull out the conveyor chain (3) below the drive until a connecting ping (4) is visible. Drive out the connecting pin using a suitable tool. Then remove the chain link (5). Reassemble in reverse order. mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020... - Page 17 Close the new conveyor chain with a connecting pin. Reassemble in reverse order. NOTE! When changing the conveyor chain always make sure that it engages positively on the drive sprocket. mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com...
-
Page 18: Adjusting Slip Clutch
(see above table). The adjusting nut is factory set to the 0˚ position. • Tighten the 3 mm Allen head screw (1) • Remount any covers or guards that may have been removed from the drive unit mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020... -
Page 19: Troubleshooting Guide
Conveyor dirty soapy water Remove the load from the conveyor and test conveyor Conveyor overloaded Check the maximum load capacity for conveyor mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 19... - Page 20 Clean conveyor system with warm, soapy water Foreign objects damage/wear out the plastic parts Identify he source of the foreign objects mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 20...
-
Page 21: Notes & Contact Information
NOTES & CONTACT INFORMATION 11.1 Record Your Notes mk North America, Inc. 105-125 Highland Park Drive Bloomfi eld, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 21... - Page 22 Technical Documentation NOTES & CONTACT INFORMATION (CONT.) mk North America, Inc. 105-125 Highland Park Drive Bloomfield, CT 06002 (860) 769-5500 www.mknorthamerica.com ©2020 Page 22...
-
Page 23: Contacting Mk North America, Inc
NOTES & CONTACT INFORMATION (CONT.) 11.2 Contacting mk North America, Inc. E-mail: sales@mknorthamerica.com Phone: (860) 769-5500 Fax: (860) 769-5505... - Page 24 North America, Inc. an mk Technology Group Company 105-125 Highland Park Drive Bloomfield, CT 06002, USA Phone: (860) 769-5500 Fax: (860) 769-5505 www.mknorthamerica.com sales@mknorthamerica.com All rights reserved, information subject to change without notice. © 2020 mk North America, Inc.
