Service Manual for:
Under-Vehicle Lift
Public Use Wheelchair Lifts
Series
DOT — Public Use Lift
DOT — Public Use Lift
"DOT — Public Use Lift" verifies that this platform lift meets the
"public use lift" requirements of FMVSS No. 403. This lift may be
installed on all vehicles appropriate for the size and weight of the
lift, but must be installed on buses, school buses, and multi-
purpose passenger vehicles other than motor homes with a gross
vehicle weight rating (GVWR) that exceeds 4,536 kg (10,000 lb).
®
®
Winamac, IN 46996 USA
FAX: (574) 946-4670
®
03
03
Read manual
before installing
or servicing lift.
Failure to do so
may result in
serious bodily
injury and/or
property damage.
W ARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UVL Series NUVL604XA and is the answer not in the manual?

Questions and answers

Summary of Contents for Braun Corporation UVL Series NUVL604XA

  • Page 1 Service Manual for: ® Under-Vehicle Lift Public Use Wheelchair Lifts Series DOT — Public Use Lift DOT — Public Use Lift “DOT — Public Use Lift” verifies that this platform lift meets the “public use lift” requirements of FMVSS No. 403. This lift may be installed on all vehicles appropriate for the size and weight of the lift, but must be installed on buses, school buses, and multi- purpose passenger vehicles other than motor homes with a gross...
  • Page 2 Congratulations We at The Braun Corporation wish to express our fullest appreciation on your new purchase. With you in mind, our skilled craftsmen have designed and assembled the finest lift available. This manual provides service-related material. Refer to the FMVSS No. 403 Quick Reference Installation Sheet for installation instructions, operating instructions and maintenance procedures.
  • Page 3: Table Of Contents

    Contents Troubleshooting and Maintenance Lift Terminology ............... 2 Switch and Sensor Locations ......... 3 Certification Checklist Diagnostic Procedures ....4 Adjustments and Calibration ........... 5 LCD Diagnostic Codes ........... 6 Floor Level and Inner Roll Stop Adjustments .... 7-10 Lubrication Diagram ............. 12 Maintenance and Lubrication Schedule ....
  • Page 4: Lift Terminology

    Lift Terminology Lift Mounting Brackets (6) Hand-Held Pendant Control Hydraulic Cylinder Inner Torque Roll Stop Tube Rolling Horizontal Arms Handrails (2) W ARN Push manu T-han lock ally move fully Failur result before e to engag drivin platfo e platfo deplo platfo ymen...
  • Page 5: Switch And Sensor Locations

    Switch and Sensor Locations Full Out Cam 75776CN Lift Out Full Out Limit Switch Limit Switch 73950A 73950A Lift Out Cam 73775 Floor Level Limit Switch 73950A Below Stow Limit Switch 73950A Floor Level 73712 Below Stow 73712 Barrier Down Limit Switch 73950RNA NING...
  • Page 6: Certification Checklist Diagnostic Procedures

    403/404 compliant. If an operation does not function as described or a condition is not met, follow the refer- enced procedures to correct the problem or contact a Braun Corporation Product Support representative. • Vehicle movement is prevented unless the lift door is closed, ensuring the lift is stowed.
  • Page 7: Adjustments And Calibration

    Adjustments and Calibration Remove eccentric plate mounting screw. Using Adjustment Procedures screwdriver or small rod, rotate the shaft clockwise to increase carriage height. Rotate the shaft coun- Lift Out Switch: The Lift Out Switch stops inward terclockwise to decrease carriage height. Reinstall travel of the carriage/platform during Stow function mounting screw in nearest retainer hole.
  • Page 8: Lcd Diagnostic Codes

    Repeat the harness diagnostic procedure. If an incorrect value is still present after checking the harness and connections, contact The Braun Corporation Product Support Department. 243R OBAR S 1 W diag Button...
  • Page 9: Floor Level And Inner Roll Stop Adjustments

    Floor Level and Inner Roll Stop Adjustments Ensure the lift is positioned and Instructions (adjust only if neces- Achieving proper floor level posi- secured as specified on the sary). tioning of the platform and inner Quick Reference Installation roll stop requires a combination of Floor Level switch adjustment Sheet supplied with the lift.
  • Page 10 Floor Level and Inner Roll Stop Adjustments Inner Roll Stop Adjustment Inner Roll Stop CAUTION Do not adjust inner roll stop clevis link. Clevis link adjust- ment may result in lift damage. Do not adjust inner roll stop clevis link at this time! Clevis link adjustment is not required unless extra usable platform length is...
  • Page 11 Floor Level and Inner Roll Stop Adjustments Inner Roll Stop Adjustment 3/8" Serrated 3. Use an Allen wrench to prevent the Flange Nut cam locking screw from turning and loosen the 3/8 serrated flange nut " securing the lifting arm cam. See Photo D.
  • Page 12 Floor Level and Inner Roll Stop Adjustments Inner Roll Stop Adjustment Do not ad- Linkage rod adjustment affects angle CAUTION of inner roll stop (vertical position). just the inner roll stop Improper inner roll clevis link stop clevis link unless extra adjustment may usable plat- result in lift damage.
  • Page 13 NOTES This page intentionally left blank. Page 11...
  • Page 14: Lubrication Diagram

    Maintenance and Lubrication Lubrication Diagram Carriage Rollers Drive Chain and Rollers (bearings) Drive Chain Release Latch Hydraulic Eccentric Cylinder Shaft Pivot Rollers Points Lifting Arm (bearings) Pivot Points Torque Rollers Tube (bearings) Pivot Points Rolling Horizontal Carriage Arm Slot Area Drive Chain W ARN...
  • Page 15: Maintenance And Lubrication Schedule

    Specified lubricants are available there is any sign of wear, damage or improper operation. from The Braun Corporation (part numbers provided on Contact your sales representative or call The Braun Cor- previous page).
  • Page 16 Maintenance and Lubrication Schedule Inspect lift for rattles Correct as needed. Check drive chain tension. Pull out and lock manual release cable. Adjust chain tension as needed. See Drive Chain Adjust- ment. Inspect inner roll stop and linkage for: Resecure, replace or correct as needed. See •...
  • Page 17 Maintenance and Lubrication Schedule Inspect limit switches and cams for securement Resecure, replace or adjust as needed. See Adjustments and Calibration. and proper adjustment Correct, replace damaged parts and/or Inspect carriage, lifting arm and eccentric shaft rollers (bearings) for wear or damage, positive relubricate.
  • Page 18: Troubleshooting Diagnosis Chart

    A Wir- Troubleshooting and yourself. Contact your dealer or ing Schematic, Hydraulic Diagram repair procedures call The Braun Corporation. One and Hydraulic Schematic are must be performed of our national Product Support provided to aid in troubleshooting.
  • Page 19 Troubleshooting Diagnosis Chart FUNCTION POSSIBLE CAUSE REMEDY 4.11 Outer Barrier switch is not Check diagnostic LCD for Outer Barrier switch sta- activated or damaged. tus. Barrier is down or barrier release pin partially 4.00 out. See Outer Barrier Occupied Calibration on LIFT WILL page 5.
  • Page 20 Troubleshooting Diagnosis Chart FUNCTION POSSIBLE CAUSE REMEDY 10.11 Poor plug connections Check harness connectors A1 and A2, E1, N1, 10.00 N2, E1, F1 and F2. BARRIER WILL NOT OPERATE 10.12 Faulty barrier actuator motor or Check power at motor. Adjust or replace actuator UP OR DOWN actuator out of adjustment if necessary.
  • Page 21 Troubleshooting Diagnosis Chart CONTACT REMOVAL 1. Remove orange wedge using 2. To remove the contacts, gently 3. Hold the rear seal in place, as needle nose pliers or a hook shaped pull wire backwards, while at the removing the contact will displace wire to pull wedge straight out.
  • Page 22 NOTES This page intentionally left blank. Page 20...
  • Page 23: Lift Wiring Schematic

    Wiring Schematic SW PWR SW PWR SW PWR IGN PWR IGN PWR IGN PWR BELOW STOW BELOW STOW BELOW STOW FULL OUT FULL OUT FULL OUT NOT FULL OUT NOT USED OR / BK LIFT OUT LIFT OUT LIFT OUT BU / BK NOT USED NOT USED...
  • Page 24: Hydraulics Parts List

    Hydraulic Parts List Item Qty. Description Part # Pump Assembly (M259 with Reservoir/with Back-up pump) 87060 Motor, Pump - 12 Volt 14785-IS Valve, “Down” (with Solenoid) 14901 Clamp, Reservoir - H-48 17069 Reservoir Replacement Kit (Includes Item #10) 88188K O-Ring (only), Hand Pump Mounting 17351 Hand Pump (Backup) with O-Rings (Includes Item #6) 87065...
  • Page 25: Hydraulics Diagram

    Hydraulic Diagram Arrow must face pump Page 23...
  • Page 26: Pump Module Parts List

    Pump Module Parts List Item Qty. Description Part # Pump Assembly, M259 87060 Adapter, 1/4” Male NPT x 7/16-20 Male JIC 37° 10130 Hose Assembly, 1/4”- F. Swivel 7/16-20 JIC 37° 32785A-154 Fitting, 90° - 7/16-20 Male JIC 37° x 1/4” Male NPT 87569 Coupling, Hydraulic Quick Connect x 1/4”...
  • Page 27: Pump Module Diagram

    Pump Module Diagram DOWN SOLENOID CIRCUIT SENTRY DOWN SOLENOID LIFT STOWED SIGNAL (OUTPUT) VEHICLE SECURE SIGNAL (INPUT) Page 25...
  • Page 28: Repair Parts List

    Repair Parts List Item Qty. Description Part No. Item Qty. Description Part No. Housing Weldment 74101NW Retainer, Scissor Bearing 73737-05 Clamp, Lift Mounting 73733 Screw, 5/16-24 x 1 1/4", Flat Head, Socket Cap 82774 Nut, 1/4" NC Rivet 83020 Platform Weldment 74301NW-02 Chain Release Assembly 73760A...
  • Page 29: Complete Lift

    Complete Lift Exploded View QTY. 4 QTY. 8 125 10 70 76 9 18 52 49 Page 27...
  • Page 30: Housing Detail

    Housing Detail Exploded View Page 28...
  • Page 31: Carriage Detail

    Carriage Detail Exploded View 70 76 9 18 52 49 Page 29...
  • Page 32: Platform Detail

    Platform Detail Exploded View QTY. 4 QTY. 8 125 10 Page 30...
  • Page 33: Braun Limited Warranty

    WARRANTY COVERAGE AND WARRANTY COVERAGE TIME PERIODS The Braun Corporation (“Braun”) warranty covers certain parts of this wheelchair lift for three (3) years or 10,000 cycles and the cost of labor to repair or replace those parts for one (1) year or 3,000 cycles. This limited warranty covers substantial defects in materials and workmanship of the lift, provided that the lift is operated and maintained properly and in conformity with the owner’s manual.
  • Page 34 ® Braun Limited Warranty This warranty does not cover, and in no event shall Braun be liable for towing charges, travel, lodging, or any other expense incurred due to the loss of use of the product or other reason. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
  • Page 35 ® Braun Limited Warranty EVENTS DISCHARGING BRAUN FROM OBLIGATION UNDER WARRANTY The following shall completely discharge Braun from any express or implied warranty obligation to repair or replace anything and void this warranty: misuse, neglect, collision, accidents, failure to provide routine maintenance (See Owner’s Manual), unauthorized alteration, off road use, Acts of Nature, damage from weather or the environment, theft, vandalism, tampering, fire, explosions, overloading the product and odometer tampering.
  • Page 36 NOTES This page intentionally left blank. Page 34...
  • Page 37 "Providing Access to the World" ® Over 300 Braun Dealers Worldwide ® "Providing Access to the World" International Corporate Hdqrs: P .O. Box 310 Winamac, IN 46996 USA 1-800-THE LIFT ® (574) 946-6153 FAX: (574) 946-4670...
  • Page 38 All illustrations, descriptions and specifications in this manual are based on the latest product information available at the time of publication. The Braun Corporation reserves the right to make changes at any time without notice. at the time of publication. The Braun Corporation reserves the right to make changes at any time without notice.
