Ingersoll-Rand SC Series Maintenance Information
Air die grinder
Hide thumbs
Also See for SC Series:
- Instructions manual (21 pages) ,
- Operation and maintenance manual (21 pages)
Related Manuals for Ingersoll-Rand SC Series
Summary of Contents for Ingersoll-Rand SC Series
- Page 1 16574956 Edition 1 May 2006 Air Die Grinder Series SC and XC Maintenance Information Save These Instructions...
- Page 2 WARNING Always wear eye protection when operating or performing maintenance on this tool. Always turn off the air supply and disconnect the air supply hose before installing, removing or adjusting any accessory on this tool, or before performing any maintenance on this tool. Note: When reading the instructions, refer to exploded diagrams in Parts Information Manuals when applicable (see under Related Documentation for form numbers).
- Page 3 into a recess. Use a bearing inserting tool similar to the Tool Specific Instructions one shown in Dwg. TPD786. 1. Assembly sequence is the reverse of disassembly. 2. First install the Throttle Lever Assembly, then the Valve Needle Bearing Inserting Tool parts.
- Page 4 Trouble Probable Cause Solution Front Rotor Bearing runs Front End Plate Spacer rubbing the bore of the Replace the Front End Plate and Front End Plate Front End Plate Spacer combination. Slow tool idle Bent or leaky Throttle Valve Replace the Throttle Valve. Rough operation/vibration Improper lubrication or dirt buildup Disassemble the Tool and clean in a suitable...
- Page 5 www.irtools.com Ingersoll Rand © 2006 Company...
