Ventis Controller Instruction Manual page 4

Your controller main screen
Auto Whirly Status
Only displayed if fitted
Operating Mode
OFF / AUTO / FLUSH / ERROR
Animated fan
Visible when the
System Fan is running
Maximum Fan Speed
25 / 50 / 75 / 100
Fan speed bar graph
Source Temperature
Appears in multiple locations
Air Source Display
Shows currently selected source,
Colour indicates mode
Room Temperature
Relative Humidity
Enabled Modes
DRYING / HEATING / COOLING /
VENTILATING
3
Filter Change Warning
Error Display
An error condition
has been detected
- what it all means
User Set Point
Adjustment form 14 C to 28 C
Hidden when in FLUSH mode
Selected
Circulation Level
LO / MID / HIGH
