Settings Menu
The Settings Menu is used to set various user preferences:
DSP BRIGHT
Display Brightness is the illumination used
when the display is inactive.
DSP DELAY (s)
Display Delay is the time (in seconds) before
the display becomes inactive.
AUTO WHIRLY
Auto Whirly (if applicable) enables or disables
the Auto Whirly fan.
HUMIDITY SPT
Set point is the room relative humidity above
which drying is enabled.

Installation Menu

The Installation Menu allows the User to observe details
about unit operation:
FAULT CODE
Fault Code Fault Code is any previously cleared
error code, normally 0.
PRODUCT
Product It displays the installed product configuration
ie: CO = Ceiling/Outside
CONFIGURE...
Configure [no longer showing on V2.43 and above]
LIVE TEST...
Live Test Live test runs through an automatic test of
all attached components of the system, this is usually
only run upon installation and when accessories are
11 added.
low
30
50
*See drying mode page 12
0
C
C = Ceiling O = Outside
T = Transfer F = Floor
number is displayed at the
Select item above
Select item below
Exit to Main Menu
Change selected value
for suggested set point
Select item above
Select item below
Exit to Main Menu
Change selected
The firm-ware version
bottom of the screen
