Connecting Instrument Cables

The power cord and USB cable connect to the ports on the rear of the instrument.
Illustration
1. Make sure that the power switch that is on the rear of the instrument is in the
Off position.
2. To use a computer to operate the instrument, connect the appropriate end of the
supplied USB cable to the USB port that is on the rear of the instrument, and then
connect the other end to a USB port on the computer.
3. To operate the instrument in standalone mode, connect one end of the 25-pin parallel
cable to the printer port, and then connect the other end to the printer.
4. Load paper into the printer according to the manufacturer's instructions and connect
the printer's power cord.
5. Connect the supplied power adapter to the power port that is on the rear of the
instrument, and then connect the other end to a grounded electrical wall outlet.
14
Part Number
5064799
4400-0002 or 4400-0036
Note: Before you connect or disconnect the power cord, make sure that the power
switch that is on the rear of the instrument is in the Off position.
Description
USB computer connection cable, 3 meter (9.8 foot)
Power cord, 1 meter (3.3 foot)
0112-0126 B
