4. If the other (ECO-M) end of the cable has not been stripped, strip the outer shielding 1 inch and then strip the black, red,
blue, and white wires 0.100 inch.
5. Disassemble the ECO-M 7-pin female connector and feed the stripped cable through the pressing screw, pinch ring,
seal, angled hood, and sleeve.
ECO-M 7-Pin Female Cable Mount Connector, Assembled (Left) and Disassembled (Right)
6. Fasten the five exposed conductors to the (1, 2, S, 5, and 6) pins on the ECO-M insert connector using the following
wiring scheme.
Pin 2, Red,
48 V DC (+)
Pin 5, Blue,
audio (-)
Pin Destinations for ECO-M 7-Pin Female Cable Mount Connector
7. Reassemble the ECO-M 7-pin female connector:
Return the sleeve to the angled hood and secure it with the insert connector.
•
Return the seal and pinch ring to the angled hood and secure it with the pressing screw.
•
8. Verify the wiring polarity is correct for both cable ends
Angled hood
Pin 1, Black,
48 V DC (–)
Pin S, Shield drain,
audio shield
Pin 6, White,
FRONT
Sleeve
Seal
Pinch ring
Pressing screw
audio (+)
MPS-482HP OPERATING INSTRUCTIONS
Insert connector
Pin 2, Red,
48 V DC (+)
Pin 5, Blue,
REAR
audio (-)
25
