C3P23LR-2051SP
Operating Instructions
! NOTE:
The heater on
your fireplace may emit a
slight, harmless odor when
first used. This odor is a
normal condition caused
by initial heating of internal
heater parts and will not
occur again.
CUTOFF SWITCH
! NOTE:
There is a safety
temperature cutoff switch
(cutout) inside the heater.
If the heater overheats, the
cutout will shut off the unit.
It can be reset by
unplugging the unit and
waiting 5 minutes before
plugging the unit back on.
CAUTION:
If you need
to continuously reset the
heater, unplug the unit and
call technical service at
1-888-346-7539
www.c3furnishings.com
The fireplace insert can be operated with the multi–function IR
remote control or from the touchscreen controls located on the top-
right corner of the fireplace.
Press any button on the remote control or touch any icon on the
touchscreen to light up and activate the controls. If no button or icon
is pressed within 10 seconds, the fireplace controls will deactivate by
turning off the icon lights.
! NOTE: To make any setting change the controls must be active.

1. Power ON/OFF

Control
7
7. Digital Display
Power ON/OFF
The Power Button turns the fireplace ON and OFF. When the
fireplace insert is OFF, pressing the Power Button twice turns the
unit ON. The first press lights up the touchscreen icons and activates
the controls. If the Power ON/OFF button is pressed again within 10
seconds it will turn off the fireplace.
The fireplace has a built-in memory function and when turned back
on it starts at the last used settings (except timer). If the fireplace is
disconnected from the main power source, it reverts to the default
settings.
1
2
3
4
5
6
Remote
1
2
3
4
5
6
Touchscreen
7
7216110100R00
