SIL Linear Series
Operating Instructions
! NOTE:
The heater on
your fireplace may emit a
slight, harmless odor when
first used. This odor is a
normal condition caused
by initial heating of internal
heater parts and will not
occur again.
CUTOFF SWITCH
! NOTE:
There is a safety
temperature cutoff switch
(cutout) inside the heater.
If the heater overheats,
the cutout will shut off the
supply power.
It can be reset by
unplugging the unit and
waiting 5 minutes before
plugging the unit back on.
CAUTION:
If you need
to continuously reset the
heater, unplug the unit and
call technical service at
1-888-346-7539.
www.c3furnishings.com
The fireplace can be operated with the multi–function IR remote
control or from the touchscreen controls on the top-right of the front
glass.
Once the fireplace is turned on the digital display and the control
icons on the front glass will illuminate. If no button or icon is pressed
within 10 seconds, the fireplace controls will deactivate by the digital
display turning off first and then the icons. To reactivate the controls
press any button on the remote or touch any icon on the front glass.

1. Power ON/OFF

4. Timer
7
7. Digital Display
Power ON/OFF
The ON/OFF button turns the fireplace ON and OFF. When the fireplace
is OFF, pressing the ON/OFF button on the remote control or touching
the icon on the front glass will turn on the fireplace. If the ON/OFF
button is pressed again within 10 seconds it will turn OFF the fireplace.
With inactive controls, press twice to turn OFF the fireplace. The first
press on the ON/OFF button lights up the touchscreen icons and
activates the controls.
The fireplace has a built-in memory function. When the fireplace is
turned back on, the display will show the last selected function and
it will start at the last used settings (except timer). If the fireplace is
disconnected from the main power source, it will restart at the default
settings.
Remote
1
2
3
4
5
6
1
2
3
4
5
6
Touchscreen
7
7215870100R00
