MICRO-EPSILON IF2008 ETH Operating Instructions Manual page 10

Hardware
IF2008 ETH
Connector Pin Signal IF2008ETH
1 A+
4a
2 A-
4b
3 B+
4 B-
4c
5 R+
6 R-
4d
7 +24 VDC
4e
8 Laser ON-
9 Multi-function output
4f
10 ERROR input
11 +5 VDC
4g
12 GND
4h
Fig. 8 Pin assignment encoder interface
1) Only for sensors
Signal Encoder
A+
A-
B+
B-
R+
R-
n.c.
1
n.c.
1
n.c.
1
n.c.
1
+5 VDC
GND
