EEI-2273
SWING CHAIR
STEP 1:
Please put all chair parts on a carpeted or padded area.
Find hardware package in the box packing Base (1/2) & Stand (3/4).
Place left Base (1) to Right Base (2) as shown.
Secure the back of base by using 3 sets of Bolts/Nuts (D).
Secure the front of base by using 2 sets of Screw Set (F).
Use Allen Wrench (J) and Open Wrench (K) to tighten Bolts/Nuts (D) clockwise until secure.
Use Phillips Head Screw Driver (Not Provided) to tighten Screw Sets (F).
Secure 10 pieces of Leveler (E) into the bottom of assembled Base as shown.
STEP 2:
Attach Lower Stand (3) to the assembled Base as shown.
Secure the back of base by using 4 sets of Bolts/Nuts (C).
Use Allen Wrench (J) and Open Wrench (K) to tighten Bolts/Nuts (C) clockwise until secure.
STEP 3:
Insert Upper Stand (3) into Lower Stand (4) as shown.
Secure by using 1 set of Bolt/Nut (B) .
Use Allen Wrench (J) and Open Wrench (K) to tighten Bolt/Nut (B) clockwise until secure.
STEP 4:
Place Cushion (7) to the assembled Basket Frame (5).
STEP 5:
Insert Spring Holder (H) into the pre-drilled hole at the top of Upper Stand (4) as shown.
Hang the assembled Basket Frame (5/6) to Upper Stand (4) by using 1 piece of Spring (G) as shown.
Bx1 Cx4
Customer Service 908-368-1025︱www.modwayfurniture.com
Dx3 Ex10 Fx1 Gx1 Hx1 Jx1 Kx1
Hardware & Tool required
