PCB Piezotronics ICP 103B11 Installation And Operating Manual page 9

Model Number
103B11
Performance
Measurement Range(± 5 V output)
Useful Overrange(± 10 V output)
Sensitivity(± 15 %)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time
Low Frequency Response(-5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector
Cable Termination
Weight
Cable Type
Cable Length
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ACOUSTIC ICP® PRESSURE SENSOR
ENGLISH SI
10 psi 190.7 dB
20 psi 196.7 dB
500 mV/psi 72.5 mV/kPa
250 psi 1724 kPa
0.06 mpsi 86.3 dB
≥ 13 kHz ≥ 13 kHz
≤ 25 µ sec ≤ 25 µ sec
5 Hz 5 Hz
≤ 2.0 % FS ≤ 2.0 % FS
≤ 0.0005 psi/g ≤ 0.0035 kPa/(m/s²)
-100 to 250 °F -73 to 121 °C
≤ 0.2 %/°F ≤ 0.36 %/°C
1000 °F 538 °C
1000 g pk 9807 m/s² pk
Positive Positive
≥ 0.1 sec ≥ 0.1 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
7 to 13 VDC 7 to 13 VDC
Ceramic Ceramic
Stainless Steel Stainless Steel
316L Stainless Steel 316L Stainless Steel
Epoxy Epoxy
Integral Cable Integral Cable
Pigtail Ends Pigtail Ends
0.115 oz 3.260 gm
32 AWG stranded wires 32 AWG stranded wires
15 in 38.1 cm
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
[1]
except where noted below. More than one option may be used.
M
- Metric Mount
Supplied Accessory : Model M061A04 Clamp (2)
[2]
NOTES:
[1] For +10 volt output, minimum 24 VDC supply voltage required. Negative 10 volt output may
be limited by output bias.
[2] Zero-based, least-squares, straight line method.
SUPPLIED ACCESSORIES:
Model 061A04 Sleeve clamp 4-40 cap screw (2)
Model 065A66 Adhesive Mounting Ring (3)
Model 070B09 Solder adaptor
Entered: LK Engineer: MJK
Date: 3/29/2019 Date: 3/29/2019
3425 Walden Avenue, Depew, NY 14043
Revision: C
ECN #: 49341
Sales: KK Approved: RPF Spec Number:
Date: 3/29/2019 Date: 3/29/2019
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
24846
