PCB Piezotronics ICP 103B11 Installation And Operating Manual page 10

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
INSTALLED WITHOUT "O-RING"
B
.300 [7.62]
2 .250 [6.35]
[ ]
 .125 THRU  3.18 THRU
   
.390 .003 MAX 9.91 0.08 MAX
A
2 EXCEEDING THIS DIMENSION WILL START LOWERING FREQUENCY RESPONSE
1 MOUNTING TORQUE SHOULD BE BETWEEN 4-5 in-lbs [4.5-5.6 Nm]
4
3
PRESSURE SENSOR
.600 [15.24]
4-40 X .43 [10.9] LG 1
CAP SCREW
W/ LOCK WASHER
(2 SUPPLIED)
MODEL 061A04
CLAMP ST STL
2 SUPPLIED
[
  
2X .089 .200
4-40 UNC - 2B  .145 4-40 UNC - 2B
3
]

2.26 5.08
PREP SURFACE WITH A Ø.500[12.70] SPOTFACE, .015-.030 [.38-.76] x, 32 FINISH MIN.
3
 3.68
CENTER SPOTFACE TO
LET SELF-CURE FOR 12 HRS. PRIOR TO TESTING. MAKE SURE SURFACE IS FREE OF DIRT, OIL,
AND DEBRIS BEFORE APPLICATION.
2.) PRESSURE SHOULD NOT EXCEED 20 PSI WHEN USING ADHESIVE MOUNTING RING
1 EXCEEDING THIS DIMENSION WILL START LOWERING FREQUENCY RESPONSE
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.01
XXX ±.005
ANGLES  2 DEGREES
FILLETS AND RADII
.003 - .005
2
REV
B
INSTALLED WITH ADHESIVE MOUNTING RING
PRESSURE SENSOR
 .375 [  9.53]
MODEL 065A66
.025 [.64] THICK
.279 [7.09] ADHESIVE MOUNTING RING
 .125 THRU
1
 
.390
.125[3.18]. APPLY 065A66 ADHESIVE MOUNTING RING, THEN SENSOR.
∅
DRAWN CHECKED
DIMENSIONS IN MILLIMETERS
JDM 7/8/20 JDM 7/8/20
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.3
XX ± 0.13
INSTALLATION DRAWING
ANGLES  2 DEGREES
PRESSURE SENSOR
FILLETS AND RADII
0.07 - 0.13
2
1
REVISIONS
DESCRIPTION DIN
UPDATED TITLE BLOCK 50900
B
.250 [6.35] 3
[ ]
 3.18 THRU
.030 .76
 
9.91
.015 .38
A
ENGINEER
RF 7/8/20
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
24844
IDENT. NO.
52681
SCALE: 2.5X SHEET 1 OF 1
1
