3 INITIAL SETUP

3.1 WHAT'S INCLUDED

•
Preselected diffraction gratings, installed and aligned
•
Electronic shutter at input port
•
A choice of single or dual output ports
•
A choice of micrometer adjustable slits, motorized or fixed slit holders at the input port and
optional output port(s)
•
Oriel LineSpec™ CCD detector adapter flange at axial output port
•
A choice of electronics interface for GPIB/RS232 or USB communication
•
LabVIEW™ based utility software
•
Application Programming Interface (API) for LabVIEW with examples
•
MonoTerm low-level command software
•
Certificate of Calibration
•
Spectrograph Power Supply
•
Line cords (U.S. and European)
•
User's manual

3.2 UNPACKING

Remove all items from the shipping containers and verify each item is accounted for. The instrument
is carefully packaged to minimize the possibility of damage during shipment. Inspect the shipping
box for external signs of damage or mishandling. Inspect the contents for damage.
If any item is missing or damaged, immediately contact Oriel Instruments or the Newport
representative from whom the system was purchased.
It is suggested to save the packaging material and shipping container, in case the equipment needs
to be relocated at a future date.

3.3 CHOOSING A LOCATION

Choose an installation location where the power requirements can be met for the spectrograph, as
well as the rest of the optical system. Be sure power is not applied to the system until the setup has
been completed and all electrical connections made.
Ensure that there is easy access to the spectrograph's power switch and the electrical outlet.
WARNING
Do not attempt to operate this equipment if there is evidence of shipping
damage or there is suspicion that the equipment will not operate
correctly. Damaged equipment may present hazards.
