- Page 1 ® Oriel LCS-100 M-66450 APEX Illuminators Small Area Sol1A 94011A 94011A-ES User's Manual Family of Brands – Corion • New Focus™ • Oriel Instruments • Richardson Gratings™ • Spectra- ® ® M94011A Rev: April 2018...
-
Page 2: Table Of Contents
M94011A ® Oriel LCS-100 Small Area Sol1A TABLE OF CONTENTS INTRODUCTION ............................ 4 SAFETY ..............................6 UV AND VISIBLE RADIATION ..................... 6 LAMP EXPLOSION ........................6 OZONE ............................7 ... - Page 3 M94011A ® Oriel LCS-100 Small Area Sol1A LIST OF TABLES SPECIFICATIONS of LCS-100 Solar Simulator ..................27 Typical Output Power from LCS-100 Solar Simulator ................27 LIST OF FIGURES Figure 1: LCS-100 Model 94011A shown with optional SA-12 Mount Plate..........5 ...
-
Page 4: Introduction
M94011A ® Oriel LCS-100 Small Area Sol1A INTRODUCTION ® The Oriel LCS-100 Small Area Sol1A Series is an integrated, compact, and easy to operate Solar Simulator. ® The Oriel LCS-100 consists of: PN 603402: light source assembly containing Factory-preset power supply igniter Lamp housing with a pre-aligned lamp mount Fan assembly with adaptive speed control for stable output Safety interlocks and thermal cutout protection... -
Page 5: Tm Model 94011A Shown With Optional Sa-12 Mount Plate
M94011A ® Oriel LCS-100 Small Area Sol1A Figure 1: LCS-100 Model 94011A shown with optional SA-12 Mount Plate and (4) 20-22-005 Leveling Feet Figure 2: LCS-100 Model 94011A-ES shown with optional SA-12 Mount Plate and (4) 20-22-005 Leveling Feet - 5 -... -
Page 6: Safety
M94011A ® Oriel LCS-100 Small Area Sol1A SAFETY SUMMARY OF HAZARDS The hazards encountered in the operation of these illuminator systems are: Radiation Lamp explosion Ozone Electrical shock Heat The interlock system is designed for your safety. Do not defeat the interlocks. UV AND VISIBLE RADIATION The high intensity UV and VIS radiation of the lamp can permanently damage the cornea, lens, and retina of the eye, even causing blindness. -
Page 7: Ozone
M94011A ® Oriel LCS-100 Small Area Sol1A 4. Attach a cover plate over the output port of any illuminator that will be used without the output enclosed, before operation. OZONE Shortwave ultraviolet radiation photolyses oxygen to produce ozone - O Relatively low concentrations of ozone can cause nasal dryness and a burning sensation in the throat, headaches, nausea, and irritation of the mucous membranes. -
Page 8: Emi
M94011A ® Oriel LCS-100 Small Area Sol1A The 94011A(-ES) housing contains EMI (Electro Magnetic Interference) under normal operating conditions. However, ignition of an arc lamp requires high voltage pulses to break the lamp down and a high current dump (10’s of Amps discharge) to sustain the arc. Arc lamp ignition creates significant electromagnetic energy. -
Page 9: General Cautions
M94011A ® Oriel LCS-100 Small Area Sol1A To avoid fire hazard, use only the specified fuse(s) with the correct type number, voltage and current ratings as referenced in the appropriate locations in the service instructions or on the equipment. Only qualified service personnel should replace fuses. ... - Page 10 This symbol indicates a burn hazard arising from elevated temperatures. European Union CE Mark The presence of the CE Mark on Newport Corporation equipment means that it has been designed, tested and certified as complying with all applicable European Union (CE) regulations and recommendations.
- Page 11 M94011A ® Oriel LCS-100 Small Area Sol1A above the power cord. The OFF symbol in the above figure indicates the OFF position of the power switch, which is located above the power cord. - 11 -...
-
Page 12: Unpacking And Assembling The System
The preferred mounting configuration for the illuminator is mounted to an optical table or breadboard type of mount plate using the Newport Model 75 Mounting Rod. This rod has 4 mount holes that are spaced to be compatible with inch and metric (25mm) holes. This rod provides the quickest approach to fine-tune the height while maintaining rotational and planar alignment with the work plane. -
Page 13: Post Clamp And Angle Bracket
POST CLAMP AND ANGLE BRACKET Remove the Newport Model 370-RC Post Clamp and 360-90 90 Degree Angle Bracket from their packaging. Use the (4) supplied 1/4 - 20 x 5/8” screws, (4) split lock washers, and (4) flat washers to attach them as shown. -
Page 14: Rod Assembly
M94011A ® Oriel LCS-100 Small Area Sol1A ROD ASSEMBLY Loosen the Model 370-RC Post Clamp. Hold the unit on the bottom in the area of the bracket near its center of mass. Slide it down the Model 75 Rod so that the rack lines up with the gear. Tighten the clamp knob. -
Page 15: Filter Installation / Replacement
M94011A ® Oriel LCS-100 Small Area Sol1A FILTER INSTALLATION / REPLACEMENT The 94011A(-ES) solar simulator includes an AM1.5G spectral correction filter. It shapes the light output to closely match the total (direct and diffuse) solar spectrum on the Earth’s surface, at a zenith angle of 48.2° (ASTM 892). -
Page 16: Figure 8: Filter Assembly Insertion And Removal
M94011A ® Oriel LCS-100 Small Area Sol1A Figure 8: Filter assembly insertion and removal 7. If a filter assembly is to be installed, remove it from its packaging and orient it so that it is angled away from the lamp toward its bottom as shown in Figure 8. 8. -
Page 17: Lamp Installation / Replacement
M94011A ® Oriel LCS-100 Small Area Sol1A LAMP INSTALLATION / REPLACEMENT ARC LAMPS Please review the safety precautions in sections: 2.2 LAMP EXPLOSION 2.4 ELECTRICAL SHOCK 2.6 HEAT 2.7 GENERAL WARNINGS 2.8 GENERAL CAUTIONS Handle the lamp carefully. Do not put significant stress on the lamp envelope or connecting wires. Gloves and eye protection are recommended to be worn when handling an arc lamp. -
Page 18: Figure 11: Lamp Retaining Clip And Retaining Posts
M94011A ® Oriel LCS-100 Small Area Sol1A retaining posts, and let it pivot back to its open position, as shown in Figure 11. Retaining Clip Retaining posts Figure 11: Lamp retaining clip and retaining posts 6. If an old lamp is in place, rotate it slightly and tilt it back so that the anode lead wire clears the lamp seating plate, then lift it out of the lamp cage slowly, and set it down gently. -
Page 19: Figure 13: Lamp Seating
M94011A ® Oriel LCS-100 Small Area Sol1A Figure 13: Lamp seating 9. Engage the lamp retaining clip over the back side of the reflector rim on either side, then within the grooved retaining post above it. Engage the other side similarly, so that the clip sits within the groove of the retaining post above it, as shown in Figure 14. -
Page 20: Figure 15: Lamp Connector Engagement
M94011A ® Oriel LCS-100 Small Area Sol1A Figure 15: Lamp connector engagement 11. Replace the lamp cage connector retention cover and screw on the thumbscrew securely. 12. If bare skin has contacted the lamp bulb be sure to cleanse the envelope thoroughly (Section 2.2). Fingerprints –... -
Page 21: Operation
M94011A ® Oriel LCS-100 Small Area Sol1A OPERATION FUSE CHANGE FOR 220VAC There are 2 fuses factory installed in the power cord jack at the rear panel, which are for 100 – 120VAC (nominal) operation. They are 1.5A type T (slo-blo). For 200 –... -
Page 22: Mounting Options
The preferred mounting configuration for the illuminator is mounted to an optical table or breadboard type of mount plate using the Newport Model 75 Mounting Rod. This rod has 4 mount holes that are spaced to be compatible with inch and metric (25mm) holes. This rod provides the quickest approach to fine-tune the height while maintaining rotational and planar alignment with the work plane. -
Page 23: Lamp Start
M94011A ® Oriel LCS-100 Small Area Sol1A Do not position the 94011A such that it is difficult to operate the power switch or remove the power cord. W.D. Figure 19: 94011A-ES Dimensions LAMP START 1. Install the desired filter in the filter holder. See Section 4 for detailed instructions. 2. -
Page 24: Shutter
M94011A ® Oriel LCS-100 Small Area Sol1A SHUTTER Open and close the shutter with the knurled knob (clockwise is open). Manual Shutter Figure 20: Manual Shutter Knob The 94011A-ES additionally has a 71446 electronic safety shutter, complete with control box, interconnecting cable, and 71449 cable for controlling the shutter from a Keithley 2400 series SourceMeter when used in conjunction with PVIV 2.0 software. -
Page 25: Irradiance Adjustment
M94011A ® Oriel LCS-100 Small Area Sol1A IRRADIANCE ADJUSTMENT There is one method of adjusting the irradiance. The lamp should be warmed up at least 10 minutes to be stable, and a detector such as the 91150V should be placed in the intended working plane to monitor the output adjustment. -
Page 26: Troubleshooting
M94011A ® Oriel LCS-100 Small Area Sol1A TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Check that the power switch is turned ON No power – blown fuse or power and the orange light in the switch is lit supply brightly. Check that power cord is fully seated. -
Page 27: Specifications
M94011A ® Oriel LCS-100 Small Area Sol1A SPECIFICATIONS SPECIFICATIONS of LCS-100 Solar Simulator Beam Size 1.5 X 1.5 inch (38mm X 38mm) Spectral Match Classification A (IEC 60904-9 2007) A (ASTM E927 – 10) Beam Non-uniformity B (IEC 60904-9 2007) B (ASTM E927 –... -
Page 28: Figure 21: Spectral Output Of Lcs-100
M94011A ® Oriel LCS-100 Small Area Sol1A Figure 21: Spectral output of LCS-100 Solar Simulator with the AM1.5G filter Figure 22: Spectral output of LCS-100 Solar Simulator with AM0 filter in place of AM1.5G filter - 28 -... -
Page 29: Figure 23: Certification Data From 94011A Solar Simulator Showing The Class A Spectral Match
M94011A ® Oriel LCS-100 Small Area Sol1A 94011A Spectral Match Ideal Match Upper Limit Lower Limit 94011A 1000 1100 Wavelength (nm) Figure 23: Certification data from 94011A Solar Simulator showing the Class A spectral match - 29 -... -
Page 30: Warranty & Service
It is available by mail request or through Newport's website. The website is where one will find product updates, interactive demonstrations, specification charts and more. -
Page 31: Repair Service
® Oriel is not obligated to accept products returned without an RMA number. Any return shipment received by Oriel® without an RMA number may be reshipped by Newport, freight collect, to the Owner of the product. NON-WARRANTY REPAIR For Products returned for repair that are not covered under warranty, Newport's standard repair charges shall be applicable in addition to all shipping expenses. -
Page 32: Loaner / Demo Material
First printing 2013 © 2013 by Newport Corporation, Irvine, CA. All rights reserved. No part of this manual may be reproduced or copied without the prior written approval of Newport Corporation. This manual has been provided for information only and product specifications are subject to change without notice.
