Litepanels™ Ringlite Mini Instructions

Directions for Powering up

Insert the female plug from the power supply into DC connector marked 9-30VDC.
Plug the power supply into 100-240VAC source. The indicator will light up red,
then green once the main power switch below the dimmer knob has been engaged.
The green LED indicates the RL-Mini fixture is ready for use. The three vertical
switches each control a separate section (top, middle, bottom) of the RL-Mini.
A power cord extension is provided to conveniently place the power supply in a more
remote location.
***Do not power the AC Adapter through a dimming device***

Directions for XLR DC connector cable

Attach the DC input connector to the 9-30 VDC input jack.
The 4-pin XLR connector attaches with a mated connector or XLR multi-pin adapter
to any 10-30 volt battery source.
Litepanels, Inc.
10932 Burbank Blvd. No. Hollywood, CA 91601
Ph. ((818) 752-7009 – Fax (818) 752-2437
www.litepanels.com
