Introduction

Thanks for using the JoMoX ModBase 09 MkII! The ModBase 09 MkII is a
great sounding, dedicated kick drum module with a real analog sound
production made for installation in 19 inch euroracks as offered by
companies like Doepfer GmbH for instance.
Actually it is a single voice storeable analog synthesizer which is optimized to
produce professional club compatible kick drum sounds. The ModBase 09
MkII module is fully controllable by CV (control voltage) / Gate as well as via
Midi. All sound parameters can be remotely controlled by either the 4 CV
inputs or via Midi CC.
All jacks are being made as 3.5mm mini jacks which is the standard in
eurorack world. You can find suitable cables in the accessories of many
eurorack modular system producing companies.
The usage is fairly simple and self-explaining at most points. Nevertheless,
we recommend to study this manual intensively in order to explore the
manyfold musical possibilities of the ModBase 09 MkII as quickly as possible.
Before we start just some important safety instructions:
 Please use the ModBase 09 MkII only in dry rooms. Please never let
fluids or humidity penetrate to the device!

The module is only made for use in so-called eurorack modular systems.
A 16 pin ribbon cable for the connection to the Doepfer system bus with
+/-12V is added. The supply voltages may not exceed +/- 15Volts.
Although there are protection diodes inside against wrong polarity we
have to warn you about wrong installation as severe damadge may
happen to the device! On a damadge caused by wrong installation or
modification of supply pins the warranty is void.
 For cleansing of the ModBase 09 MkII, please use a slightly damp cloth,
never solvents or agents!

The ModBase 09 MkII is a complex electronic device and should
therefore be treated carefully!
If any damadges or malfunctions occur, please immediatly turn off the rack,
take the module out of the rack and contact your local music dealer or send
an email to mail@jomox.de.
