<Important>
Be sure to correctly follow the procedures in order as explained in this Installation Manual.
If you do not follow the procedure in order, the image trouble may occur.
1. Outline of installation procedures
MK-602
When installing the main body and associated options as a system, follow the order shown on the upper.
Caution:
• Lifting the main body in an awkward position or transporting it in a poorly balanced position could result in
personal injury. When transporting the main body, assign an adequate number of persons to the job and
ensure that each person can take a good position of not being excessively loaded.
(mass: approx. 72 kg (158-3/4 lb))
Note:
• For the detailed installation procedures for each option, follow the instructions given in the corresponding
installation manual and perform the procedures correctly.
• When placing the main body on the floor, make sure to use the paper feed cabinet or the desk to secure
the performance and the quality of the product.
• To use this machine, install the reverse automatic document feeder or the original cover.
• Once the Power Switch is turned ON, do not turn OFF it until the installation work has been completed.
2016. 1
Printed in China
INSTALLATION MANUAL
PC-114
PC-214
KH-102
FK-513
HD-522*
EK-608
AU-102
AU-201S
SP-501
DF-628
FS-533
JS-506
PK-519
/
Applied Machines:
HT-509
MK-734
PC-414
DK-514
UK-211
Machine
KP-101
EK-609
UK-212
WT-506
MK-735
OC-514
CU-101
MK-748
MK-603
FS-534
RU-514
PK-520
E-1
*: Varies depending on the
applicable marketing area
FS-534SD
/
A797-9601-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Konica Minolta Bizhub C287
Summary of Contents for Konica Minolta Bizhub C287
- Page 1 INSTALLATION MANUAL Applied Machines: <Important> Be sure to correctly follow the procedures in order as explained in this Installation Manual. If you do not follow the procedure in order, the image trouble may occur. 1. Outline of installation procedures HT-509 MK-734 PC-114 PC-214...
- Page 2 2. Installation space (unit: mm (inch)) 3. Pre-installation check items bizhub C287 + DF-628 + PC-214 + FS-534 (1) Select a level and stable place for installing the + MK-748/CU-101 machine. (2) Be sure to use a power source of the voltage and...
-
Page 3: Accessory Parts
5. Accessory parts 6. Installing the main body and the Paper Feed Cabinet (or the Desk) Name Q’ty (1) Take the main body and the Paper Feed Cabinet 1. User’s guide holder (or the Desk) out from its packaging. 2. Quick start guide Caution: 3. - Page 4 7. Removing protective tape, packing and (2) Open the right door and remove the locking materials. other shipping materials Note: (1) Remove the protective tape and the protective • After removing the locking materials, make sure materials. that the transfer roller assy is secured in place. In the case of <NG>, press the transfer roller assy into place so that it is secured as shown in <OK>.
- Page 5 (4) Move the fusing adjustment lever down to the (9) Slide out the tray 2. printing position (bottom). (10) Remove the protective tape from the inside of the tray 2 and remove accessory parts. (5) Close the right door. (6) Remove the protective film from the control (11) Remove the locking material at the left side of panel.
-
Page 6: Installing The Toner Cartridge
(14) Remove the protective tape. (18) Slide the drum unit (K) into the machine. (19) Lock the drum unit (K) with the lever. (20) Install the supplied waste toner box. Note: • Push the areas indicated by the “ ” marks to set the waste toner box to the machine. -
Page 7: Installing Other Options
10. Mounting the accessory parts (2) Insert the toner cartridge into the machine. Note: (1) Set the stylus pen in the place shown in the illus- • Make sure that the color is same between tration. inserting port and the toner cartridge. •... -
Page 8: Connecting The Power Cord
11. Connecting the power cord 12. Starting the machine (1) Connect the power cord. Turn ON the power switch on the right side of the main body. Note: This may not be performed depending on the applicable marketing area. 13. Date & Time Setting/Time Zone Setting (Service Mode) (1) Display the Service Mode screen. -
Page 9: Configuring Other Options
16. Performing Non-Image Area Erase 17. Configuring other options Check (1) If any of the following options are installed, refer to the “Configuration procedures” of the installa- Note: tion manual for each option and configure the Perform the below at the site where customer option(s). - Page 10 22. Affixing the paper size label (2) Check LEDs for lighting conditions. LED1: Affix the paper size labels that correspond to the Should light up steadily if the link network con- sizes of paper used in each tray. nection has been made. LED2: Should blink according to the communications status of the ACT network.
-
Page 11: Installation Procedures
OC-514 Original Cover INSTALLATION MANUAL 1 Accessory parts 2. Installation procedures (1) Remove the two knockouts using nippers or a Name Shape Q’ty similar tool. 1. Original cover 2. Original mat 3. Hinge cover (right) 4. Hinge cover (2) Attach the supplied hinge cover (right) and hinge (left) cover (left). - Page 12 (4) Using a cleaning pad dampened with alcohol, (8) Gently press the original cover. wipe the undersurface of the original cover, where the original mat is attached. (9) Open the original cover and press on the original mat firmly so that it does not peel off. (5) With the double-sided tape facing up, position the original mat on the original glass.
