Calibration Chamber; Removing The Calibration Chamber - Knick SensoGate WA 133 Series User Manual

Retractable fitting with ptfe process adaptation

Table of Contents

Calibration Chamber

SensoGate WA 133

1. Screw off the outlet (AM) and

2. Loosen and remove the two

3. Pull the calibration chamber

4. Push the flange bushing (N)

inlet connectors (AV). Take off

the loose flange if required.

screws (AK) from the calibration

chamber (using screwdriver

TX25).

(K) vertically out of the process

adaptation (P).

downwards out of the process

adaptation.

Now, the gaskets are accessi-

ble and can be checked and

replaced if required.
