hager FWU Series Manual

Field distributor flush-mounted enclosures protection type ip30
Hide thumbs
Table of Contents

Advertisement

Quick Links

univers FW manual
Field distributor
Flush-mounted
enclosures FWU
Protection type IP30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FWU Series and is the answer not in the manual?

Questions and answers

Related Manuals for hager FWU Series

Summary of Contents for hager FWU Series

  • Page 1 univers FW manual Field distributor Flush-mounted enclosures FWU Protection type IP30...

  • Page 2: Table Of Contents

    Table of contents Table of contents About this manual Subject of the manual Warranty and Liability Used symbols and trademarks For your safety Proper use Requirements for authorised personnel Technical data About the FWU field distributor Delivery form Body/wall cabinet 4.2.1 Features 4.2.2...
  • Page 3 Table of contents Kit pre-mounted 6.2.1 Distributor kits UWxxUx 6.2.2 Multimedia kits 6.2.3 Hybrid kits Kits to assemble 6.3.1 UN0xFN vertical uprights 6.3.2 UZ0xAx tower parts 6.3.3 U… DIN rail 6.3.4 UM00M0 plastic mounting plate 6.3.5 Metal mounting plates UZxxMx Multimedia accessories 6.4.1 Patch panels without socket holder...

  • Page 4: About This Manual

    Warranty and Liability These instructions do not extend the Sales and Delivery Conditions of Hager. No new claims concerning the warranty or guarantee, which extend beyond the Sales and Delivery Conditions, can be derived from this instruction manual.

  • Page 5: Used Symbols And Trademarks

    About this manual Used symbols and trademarks Structure of warning messages Signal word Type and source of the danger! Consequences if the danger is ignored  Measures for averting the danger Danger levels in warning messages Colour Signal word Consequences of non-compliance DANGER Death, serious personal injury WARNING...

  • Page 6: For Your Safety

    The Hager FWU field distributor has been equipped with components from the univers FW internal fitting system. Hager’s tried and tested FWU field distributor and the univers FW internal fitting system enable the implementation of switchgear and controlgear assemblies according to EN 61439 Part 3 (Distribution boards intended to be operated by ordinary persons / DBO).
  • Page 7 For your safety Limitation of operating areas There are certain areas in which the FWU field distributor enclosure may not be used, in order to prevent hazards or damage to the enclosure. The field distributor is not suitable for use: in areas that require a higher protection type, in areas where ATEX directives must be observed, in operating sites at risk of fire,...

  • Page 8: Requirements For Authorised Personnel

    For your safety Requirements for authorised personnel - Only qualified electrically skilled persons may assemble, install, commission switchgear and controlgear assemblies, perform extensions, troubleshooting or maintenance and disassemble and dispose of them. - The qualified electrically skilled persons must have appropriate experience in initial testing and subsequent commissioning, troubleshooting and maintenance.

  • Page 9: Technical Data

    Technical data Technical data Intended use Observing the technical data is important for ensuring the intended use. Specifications for switchgear and controlgear assemblies The FWU field distributor has been equipped to receive the univers FW internal fitting system (with UN0xFN vertical uprights). After being appropriately extended, it is suitable as a switchgear and controlgear assembly according to EN 61439-1/-3 for: Frequency f...
  • Page 10 Technical data Mechanical installation of devices /internal fittings Equipped to receive the univers FW internal fitting system Compatible with specific univers Z and univers N accessories (restrictions due to size) For assembly on univers FW UN0*FN vertical uprights (not included for empty enclosures) Internal fitting system pre-mounted in complete enclosures, fast assembly/disassembly thanks to snap-in technology...
  • Page 11 Technical data Materials Door and frame: Steel, 1 mm thick Powder-coated with epoxy polyester paint then baked Metal plate wall cabinet made of hot-dip galvanised steel, 1 mm thick Material for insulated parts: Polystyrene (PS): Covers, head/foot sections, rear panel, extrusion profile Polycarbonate/acrylonitrile styrene acrylate (PC/ASA): Corner sections, multimedia panel Polycarbonate (PC): Multimedia door inserts...

  • Page 12: About The Fwu Field Distributor

    About the FWU field distributor About the FWU field distributor Delivery form The new FWU field distributor is delivered in two different forms: As a complete system: Order number comprises wall cabinet, door and frame. With certain products such as FWU52GS, the internal fitting system is already included.
  • Page 13 About the FWU field distributor As individual parts: To start with, the wall cabinet is ordered without a frame or door. The customer must then order the frame, door and internal fitting system separately. This form of delivery is particularly useful if the wall cabinet is to be installed at the building site at a much earlier stage, or if a special door is requested which is not available as part of a complete system (e.g.

  • Page 14: Body/Wall Cabinet

    About the FWU field distributor Body/wall cabinet 4.2.1 Features Can be turned 180° (top/bottom) Interior is double-insulated with plastic parts Cable duct (11 cm²) is built-in laterally inside the box 2 cut-outs (top/bottom) on each side for lateral cable routing up to M40 2 cut-outs (top/bottom) per panel for rear cable routing Removable transverse cleats at top/bottom for cable entry from the front (sliding bottom and top cable entry)
  • Page 15 About the FWU field distributor Cable entries Additional cable entry areas New cable entries have been added to the side and rear of the new FWU field distributor. The cable entry area of the top and bottom slider is 120 cm². That’s 17% larger than on the former FW (103 cm²).
  • Page 16 About the FWU field distributor Top and bottom cable entries 2 snap-in cable entries per field (one at the top and one at the bottom) Can be removed from the front (slider technology) Max. cable entry area: 188 x 60 mm With pre-punches that can be cut out for different empty conduit diameters: 7 x Ø21/26 mm 6 x Ø15/26 mm...
  • Page 17 When cutting out the maximum opening area, the FD00P5 accessory can be installed to provide passive ventilation in the following cases: Hollow wall installation Availability of a side cavity area (Hager recommends allowing a distance of 50 mm between the cavity and the front of the FD00P5 ventilation inserts)
  • Page 18 About the FWU field distributor Dimensions and position Cable entries at the rear 2 cable entries on each side (one at the top and one at the bottom) Can be pushed out from the outside (before installing in the wall) Max.
  • Page 19 About the FWU field distributor Dimensions and position of the rear cable entries Enclosure with flange VZ741 mounted on the top rear cable entry (view from the front) Technical changes reserved...
  • Page 20 About the FWU field distributor Top/bottom cable strain relief At the top and bottom, the FWU enclosure contains a built-in option for attaching conduits and cables using cable ties. For each 250 mm-wide panel, there are 13 insertion points for cable ties. Thanks to a special guide, cable ties with a maximum width of 12 mm can be easily pushed into the duct and come out again on the other side, at the front.
  • Page 21 About the FWU field distributor Side vertical cable duct The wall cabinet of the FWU enclosure includes side cavities for routing cables vertically. They form a duct on each side with a cross section of 11 cm² (approx. 60 x 18 mm). They enable several cables to be routed from top to bottom or vice versa if the area beneath the DIN rails is no longer large enough.
  • Page 22 About the FWU field distributor Cables held in place by cable duct clips 4 cable duct clips are attached to each enclosure. They are inserted diagonally and clicked into place in the cable duct, similarly to the M7239 clips in the Tehalit LFH cable trunking system (60 mm).
  • Page 23 About the FWU field distributor Cable duct cover With multimedia complete enclosures (FWUxxK, etc.), a cable duct cover is pre-mounted at the side next to the multimedia field. This halogen-free cover can also be clipped into place over the clips (similarly to the Tehalit LFH cable trunking system).

  • Page 24: Coding

    About the FWU field distributor 4.2.2 Coding The order number code for flush-mounted field distributor enclosures has been re-defined in the style of the surface-mounted field distributor enclosure (FWB/FWQ...). The coding is made up of three components: Enclosure type: FWU… Enclosure dimensions (height and width): FWU32…...

  • Page 25: Overview Of Enclosure Product Codes

    About the FWU field distributor 4.2.3 Overview of enclosure product codes Size 3 Enclosure width 300 mm 550 mm 750 mm FWU31A FWU32A FWU33A FWU31D FWU32D FWU33D FWU32GS Enclosure FWU32K1 height 500 mm FWU32K2 FWU31L FWU32L FWU33L FWU32M2 FWU31S FWU32S FWU33S FWU31S1 FWU32S1...
  • Page 26 About the FWU field distributor Size 6 Enclosure width 300 mm 550 mm 750 mm FWU61A FWU62A FWU63A FWU61D FWU62D FWU63D FWU62GS FWU62K Enclosure FWU62K1 height 950 mm FWU62K2 FWU61L FWU62L FWU63L FWU62M2 FWU62N FWU63N FWU61S FWU62S FWU63S FWU61S1 FWU62S1 FWU63S1 Size 7 Enclosure width...

  • Page 27: Enclosures In Detail

    About the FWU field distributor 4.2.4 Enclosures in detail FWUxxA Product code FWU31A FWU32A FWU33A FWU41A FWU42A FWU43A FWU51A FWU52A FWU53A FWU61A FWU62A FWU63A FWU71A FWU72A FWU73A Example: FWU33A Internal fittings Distributor kit(s): - Slot width for 12 modules - Distance between DIN rails: 125 mm Without QuickConnect and without QuickConnect support Door: - Closed...
  • Page 28 About the FWU field distributor FWUxxD Product code FWU31D FWU32D FWU33D FWU41D FWU42D FWU43D FWU51D FWU52D FWU53D FWU61D FWU62D FWU63D FWU71D FWU72D FWU73D Example: FWU41D Without internal fitting system Door: - Closed - Steel - univers door handle - From size 5, right-hand door with stiffener strip Included in the scope of delivery: - 4 cable clips - DIN A4 label strips with type label...
  • Page 29 About the FWU field distributor FWUxxGS Product code FWU32GS FWU42GS FWU52GS FWU62GS FWU72GS Example: FWU62GS Internal fittings Distributor kit(s): - Slot width for 12 modules - Distance between DIN rails: 125 mm QuickConnect configuration (at the top of each distributor kit) Height 3: 2x KN10E + KN18E...
  • Page 30 About the FWU field distributor FWUxxK Product code FWU42K FWU43K FWU52K FWU53K FWU62K Example: FWU43K Internal fittings Distributor kit(s): Multimedia kit: - Slot width for 12 modules - Pre-mounted plastic mounting plates - Distance between DIN rails: 125 mm - Number of mounting plates per size: see UMx1UK - Cable duct cover FWU00Cx pre-mounted on the outside next to the...
  • Page 31 About the FWU field distributor FWUxxK1 Product code FWU32K1 FWU42K1 FWU52K1 FWU62K1 FWU72K1 Example: FWU42K1 Internal fittings Distributor kit: Multimedia kit: - Slot width for 12 modules - Pre-mounted plastic mounting plates - Distance between DIN rails: 125 mm - Number of mounting plates per size: see UMx1UK - Cable duct cover FWU00Cx pre-mounted on the outside next to the...
  • Page 32 About the FWU field distributor FWUxxK2 Product code FWU32K2 FWU42K2 FWU52K2 FWU62K2 FWU72K2 Example: FWU52K Internal fittings Distributor kit: Multimedia kit: - Slot width for 12 modules - Pre-mounted plastic mounting plates - Distance between DIN rails: 125 mm - Number of mounting plates per size: see UMx1UK - Cable duct cover FWU00Cx pre-mounted on the outside next to the...
  • Page 33 About the FWU field distributor FWUxxL Product code FWU31L FWU32L FWU33L FWU41L FWU42L FWU43L FWU51L FWU52L FWU53L FWU61L FWU62L FWU63L FWU71L FWU72L FWU73L FWU81L Example: FWU42L Without internal fitting system Without frame and without door Included in the scope of delivery: - 4 cable clips - DIN A4 label strips with type label - DIN A4 circuit table...
  • Page 34 About the FWU field distributor FWUxxM2 Product code FWU32M2 FWU42M2 FWU52M2 FWU62M2 FWU72M2 Example: FWU72M2 Internal fittings Distributor kit: - Slot width for 26 modules - Continuous DIN rails (500 mm wide) - Distance between DIN rails: 125 mm QuickConnect configuration (top) Height 3: 2x KN22E Height 4:...
  • Page 35 About the FWU field distributor FWUxxN Product code FWU52N FWU53N FWU62N FWU63N FWU72N FWU73N Example: FWU63N Internal fittings 2 top rows: - For terminal blocks - Closed covers - Insulated DIN rails UT22C - Distance between DIN rails: 150 mm Distributor kit(s): - Slot width for 12 modules - Distance between DIN rails: 150 mm...
  • Page 36 About the FWU field distributor FWUxxS Product code FWU31S FWU32S FWU33S FWU41S FWU42S FWU43S FWU51S FWU52S FWU53S FWU61S FWU62S FWU63S FWU71S FWU72S FWU73S Example: FWU61S Internal fittings QuickConnect configuration (at the top of each distributor kit) Height 3: 2x KN10E + KN18E Heights 4, 5, 6 and 7: 2x KN10E...
  • Page 37 About the FWU field distributor FWUxxS1 Product code FWU31S1 FWU32S1 FWU33S1 FWU41S1 FWU42S1 FWU43S1 FWU51S1 FWU52S1 FWU53S1 FWU61S1 FWU62S1 FWU63S1 FWU71S1 FWU72S1 FWU73S1 Example: FWU73S1 Internal fittings QuickConnect configuration (at the top of each distributor kit) Height 3: KN18E Heights 4, 5, 6 and 7: KN22E Door: - Closed...

  • Page 38: Frames And Doors

    About the FWU field distributor Frames and doors 4.3.1 Features Front-flush, door can be closed from the right or left Can be dismantled without tools Inside, adjustable hinge Available with metal plate doors (closed door), clear doors (transparent door) or multimedia plastic doors (multimedia door) Double door on enclosure width 800 mm (3 fields) Door opening angle: 110°...
  • Page 39 About the FWU field distributor Notes for installing the door: Distance of door to interior fitting elements Technical changes reserved...

  • Page 40: Coding

    About the FWU field distributor 4.3.2 Coding The order number code for frames with door comprises: the type of enclosure: FZ1... the housing dimensions (height and width): FZ142NV1 the door designation: FZ142NV1 Product Door code Door type handle ending Frame with closed door FZ598 Frame with closed multimedia door FZ598...

  • Page 41: Door Product Codes: Single Doors With Univers Door Handle

    About the FWU field distributor 4.3.3 Door product codes: Single doors with univers door handle Closed door, max. IP44, univers door handle Width 1 (300 mm) Width 2 (550 mm) Width 3 (800 mm) Left-hand Right-hand Left-hand Right-hand Left-hand Right-hand Height door door...
  • Page 42 About the FWU field distributor Transparent door, max. IP30, univers door handle Width 1 (300 mm) Width 2 (550 mm) Width 3 (800 mm) Left-hand Right-hand Left-hand Right-hand Left-hand Right-hand Height door door door door door door 3 (500 mm) 4 (650 mm) FZ006FT FZ006FT...

  • Page 43: Door Product Codes: Single Doors With 90Sl Door Handle

    About the FWU field distributor 4.3.4 Door product codes: Single doors with 90SL door handle Closed door, max. IP44, 90SL door handle Width 1 (300 mm) Width 2 (550 mm) Width 3 (800 mm) Left-hand Right-hand Left-hand Right-hand Left-hand Right-hand Height door door...

  • Page 44: Overview Of Flush Frame Product Codes

    About the FWU field distributor 4.3.5 Overview of flush frame product codes Size 3 Enclosure width 300 mm 550 mm 750 mm Enclosure height FZ031F FZ032F FZ033F 500 mm Size 4 Enclosure width 300 mm 550 mm 750 mm FZ041F FZ042F FZ043F Enclosure...

  • Page 45: Frame Details

    About the FWU field distributor Size 8 Enclosure width 300 mm 550 mm 750 mm FZ081F Enclosure FZ181F height FZ181FM2 1250 mm FZ181NM FZ181NV1 4.3.6 Frame details FZ0xxF Example: FZ042F Frame without a door for ordering as individual parts Can be combined with wall cabinet FWUxxL Included in the scope of delivery: 4 screws for fixing to the wall cabinet An overview of all frame sizes is illustrated in the table below:...
  • Page 46 About the FWU field distributor The required FZ… door to match the corresponding frame size must be selected from the table in “Overview of door product codes”. As all right-hand doors can be installed as double doors and as single doors, they must be pre-mounted with two door rods for 3-point attachment in the centre of the enclosure.
  • Page 47 About the FWU field distributor FZ1xxF Product code FZ141F FZ142F FZ143F FZ151F FZ152F FZ153F FZ161F FZ162F FZ171F FZ181F Example: FZ142F Frame with door for ordering as individual parts Can be combined with wall cabinet FWUxxL Door: Closed Steel 90SL door handle From size 5, right-hand door with stiffener strip On enclosure sizes 53 and 63, closed left-hand door made of steel (without plastic)
  • Page 48 About the FWU field distributor FZ1xxFM2 Product code FZ141FM2 F14Z2FM2 FZ143FM2 FZ151FM2 FZ152FM2 FZ153FM2 FZ161FM2 FZ162FM2 FZ171FM2 FZ181FM2 Example: FZ181FM2 Frame with door for ordering as individual parts Can be combined with wall cabinet FWUxxL Door: Closed, multimedia Steel frame Plastic insert in the centre for better WLAN access, opaque (not transparent) 90SL door handle...
  • Page 49 About the FWU field distributor FZ1xxNM Product code FZ141NM FZ142NM FZ143NM FZ151NM FZ152NM FZ153NM FZ161NM FZ162NM FZ171NM FZ181NM Example: FZ143NM Frame with door for ordering as individual parts Can be combined with wall cabinet FWUxxL Door: Slotted, multimedia Steel frame Slotted plastic panel in the centre for better WLAN access, opaque (not transparent) univers door handle...
  • Page 50 About the FWU field distributor FZ1xxNV1 Product code FZ141NV1 F14Z2NV1 FZ143NV1 FZ151NV1 FZ152NV1 FZ153NV1 FZ161NV1 FZ162NV1 FZ171NV1 FZ181NV1 Example: FZ162NV1 Frame with door for ordering as individual parts Can be combined with wall cabinet FWUxxL Door: Slotted Steel univers door handle From size 5, right-hand door with stiffener strip On enclosure sizes 53 and 63, slotted left-hand door made of steel (without plastic)

  • Page 51: Assembling The Body/Wall Cabinet

    Assembling the body/wall cabinet Assembling the body/wall cabinet Protected and packaged during transport/integrated plaster guard The FWU field distributor is fully packaged similarly to in a shoe box. This protects it more effectively from scratches, dust or white rust than the former FW version.

  • Page 52: Fd00P5 Ventilation Insert

    Assembling the body/wall cabinet 5.2.2 FD00P5 ventilation insert Ventilation panels for flush-mounted/hollow wall applications can be mounted on the side of the enclosure. The FD00P5 ventilation insert is suitable for improving ventilation. Two FD00P5 ventilation inserts are provided in the set. It only makes sense to use the FD00P5 ventilation insert if there is a cavity behind the wall, e.g.
  • Page 53 To ensure optimum air circulation, Hager recommends keeping an area of 50 mm clear in front of the ventilation openings. Also observe the following: When using VZ405N hollow wall anchors, leave a space of at least 32 mm so that the anchors can be flipped forward unhampered.

  • Page 54: Enclosure-To-Enclosure Connection With The Fwu00F1 Connection Set

    Assembling the body/wall cabinet 5.2.3 Enclosure-to-enclosure connection with the FWU00F1 connection set Two enclosures can be mechanically connected together with the aid of the FWU00F1 connection set. They can be connected next to or above one another. Frames can then be flush-mounted with the aid of the connection set. Flush-mounting of frames over two wall cabinets connected together Width of bracket in the FWU00F1 connection set Technical changes reserved...
  • Page 55 Assembling the body/wall cabinet Horizontal enclosure-to-enclosure connection The FWU00F1 connection set enables two wall cabinets to be mechanically attached together via the elongated holes at the sides with the aid of two C-angle brackets. All 4 holes in the brackets are lined up horizontally. The 2 brackets for the horizontal connection are 50 mm wide.

  • Page 56: Wall Installation

    Assembling the body/wall cabinet Wall installation 5.3.1 Wall installation measurement/dimensions Wall installation measurements for a wall niche or a hollow wall are provided in installation manual 6LE005468 which is supplied with the enclosure: A (mm) B (mm) C (mm) D (mm) FWU31…...
  • Page 57 Assembling the body/wall cabinet Dimensions of the wall niche or hollow wall for the enclosure installation Technical changes reserved...

  • Page 58: Wall Installation Options

    Assembling the body/wall cabinet 5.3.2 Wall installation options The wall cabinet can be attached to the wall in 3 different ways: With the aid of built-in wall supports Via the elongated holes on the sides of the body Using VZ405N hollow wall anchors (accessory) Attaching the wall cabinet to the wall with the aid of built-in wall supports The wall cabinet can be screwed into the wall with the aid of the built-in wall supports (which are bent back).
  • Page 59 Assembling the body/wall cabinet Attaching the wall cabinet using VZ405N hollow wall anchors Important note: If installing the wall cabinet in a hollow wall, ensure that the weight of the enclosure is sufficiently supported from below. The wall cabinet can also be installed inside a hollow wall using the hollow wall anchors.

  • Page 60: Using The Plaster Guard

    Assembling the body/wall cabinet 5.3.3 Using the plaster guard As standard, a full-size plaster guard made of reinforced corrugated paper is included in the scope of delivery of the FWU field distributor. After installing the wall cabinet in the wall, fold back the plaster guard along the perforated line on each edge, and insert into the wall cabinet up to the stop.

  • Page 61: Univers Fw Internal Fitting System

    univers FW internal fitting system univers FW internal fitting system Coding The FWU enclosure is equipped to receive univers FW kits. The univers FW kits use vertical uprights made of profiled and galvanised steel plate with a 13 mm-deep U profile. These vertical uprights are 14 mm thinner than the univers vertical uprights and are therefore suitable for compact installation in a wall niche 110 mm deep.

  • Page 62: Kit Pre-Mounted

    univers FW internal fitting system Kit pre-mounted 6.2.1 Distributor kits UWxxUx Distributor kits comprise: vertical uprights DIN rails QuickConnect terminals and supports Support towers Covers From size 7 (1100 mm), two covers are used on top of one another. With all covers, the distance between the rows of modules is 125 mm (slits).

  • Page 63: Multimedia Kits

    univers FW internal fitting system 6.2.2 Multimedia kits UMx1UK As part of the FWU field distributor project, new plastic plates have been developed for multimedia applications. These new kits with 250 mm-wide plastic plates can be ordered under product code UMx1UK: Number of Number of Width 1...
  • Page 64 univers FW internal fitting system Mounting the UMx1UK plastic mounting plate Left: on the front of the vertical uprights Right: on the back of the vertical uprights In each UMx1UK support frame, the lower plate is positioned at 75 mm from the lower edge of the vertical upright so that the Volta triple socket can be mounted directly underneath.
  • Page 65 univers FW internal fitting system UNxxTN The existing UNxxTN multimedia kits with perforated plates are still available. They are composed of one single plate that cannot be moved downwards. These kits are are 250 or 500 mm wide. With all these product codes, 20 plate screws (short and long) are supplied for directly attaching multimedia devices.

  • Page 66: Hybrid Kits

    univers FW internal fitting system 6.2.3 Hybrid kits The following hybrid kits from the former FW enclosure range are still available. They consist of rows of modules at the top and mounting plates at the bottom. UMx1U1/UMx1U2/UMx1U3/UMx1U4 (Switzerland) The ...1U1 to ...1U4 modules are intended for Switzerland, and include an FLF 4-way socket.
  • Page 67 univers FW internal fitting system Width 1 Height (250 mm) 3 (450 mm) Multimedia kit with FLF 4 (600 mm) 4-way 5 (750 mm) socket, green/yellow 6 (900 mm) QC, partition 7 (1050 mm) UM71U3 and 3 DIN rails 8 (1200 mm) UM81U3 Example: UM71U3...
  • Page 68 univers FW internal fitting system UMx1UM3 / UMx1UM4 The UM3 to UM4 modules do not have a socket but are equipped at the top with a QuickConnect support with 2 x KN10N and KN22E. The modules include a green/yellow cable H07V-K 1.5 mm² for the equipotential bonding, and a horizontal partition ZZ10H.
  • Page 69 univers FW internal fitting system Hybrid kits in the lower section without a cover or multimedia kits do not have a protection class. When using multimedia kits (without covers), all devices and wiring must be equipped with protective insulation or double insulation. This is the only way to guarantee protection class II.

  • Page 70: Kits To Assemble

    univers FW internal fitting system Kits to assemble Kits can be assembled out of individual parts. The following section lists the corresponding accessories. 6.3.1 UN0xFN vertical uprights Width 1 Section Height (250 mm) 3 (450 mm) UN03FN 4 (600 mm) UN04FN 5 (750 mm) UN05FN...

  • Page 71: Din Rail

    univers FW internal fitting system 6.3.3 U… DIN rail U842B: Standard DIN rail UT22C: Insulated DIN rail, lowered 1 field wide, depth-adjustable up to 21 mm 6.3.4 UM00M0 plastic mounting plate The new UM00M0 plastic mounting plate is 250 mm wide and 175 mm high. The plate can be screwed onto the vertical uprights from the univers FW range (UZ0xFN) and is built as standard into the new UMx1UK FWU multimedia kits.
  • Page 72 univers FW internal fitting system The mounting plate offers various functions: Mounting of cable ties Mounting of univers FZ913 cable clips Installation of the VZ02MM modem holder Quick fastening of VZ340 rubber bands Depth positioning beneath the vertical uprights Cable ties mounted on UM00M0 plastic VZ02MM modem holder mounted on mounting plate UM00M0 plastic mounting plate...
  • Page 73 univers FW internal fitting system Mounting the UM00M0 plastic mounting plate on the back of vertical uprights Mounting plate attached to the back of the vertical uprights (top of picture) and to the front of the vertical uprights (bottom of picture) If the mounting plate is installed in the head/foot section area (area at <...

  • Page 74: Metal Mounting Plates Uzxxmx

    univers FW internal fitting system 6.3.5 Metal mounting plates UZxxMx Width Width Height 248 mm 498 mm UZ31M5 UZ32M5 Metal UZ41M5 UZ42M5 mounting plate UZ51M5 UZ52M5 (rectangular) UZ61M5 UZ62M5 Example: UZ42M5 Width Height 248 mm UZ21M6 UZ31M6 Metal UZ41M6 mounting plate (elongated) UZ51M6 UZ61M6...

  • Page 75: Multimedia Accessories

    univers FW internal fitting system Multimedia accessories The FWU field distributor is equipped to receive the multimedia extension. You can choose between multimedia kits with perforated mounting plates or with new plastic mounting plates. In the K enclosure versions, multimedia kits are supplied with pre-installed plastic plates.
  • Page 76 univers FW internal fitting system Assembled enclosure, mounted multimedia panels on the right, patch panel (top), triple socket (bottom) and their respective covers A patch panel can be mounted horizontally at the top on the vertical uprights by screwing the metal support into the bottom hole of the third hole pattern (position 87.5 mm from the top).
  • Page 77 univers FW internal fitting system A special cover can be mounted on top. Before doing so, 2 tower overparts (UZ02A1) must be inserted. The cover has 2 claws at the front which engage under the support. Installing the patch panel cover with 2 tower overparts The cover can also be screwed onto the plate support with the aid of the visible pre-punch in the central area.
  • Page 78 univers FW internal fitting system Mounted Volta triple socket and cover (not yet mounted) As in the patch panel area, a special cover can also be mounted here. Before doing so, 2 tower overparts (UZ02A1) must be inserted. The cover can be ordered with product code UM00S3 or with the UM00S1 set. With both of these items, the tower overparts are already included.

  • Page 79: Patch Panels Without Socket Holder

    univers FW internal fitting system 6.4.1 Patch panels without socket holder In the FWU field distributor, full patch panels with different patch formats can also be mounted. Dimensions of patch panel openings HMS system E-DAT Keystone Lexcom Technical changes reserved...
  • Page 80 univers FW internal fitting system UM00K4/UM00K5/UM00K6 The UM00K4, UM00K5 and UM00K6 supports comprise between 18 and 24 patch openings in E-DAT, Keystone or Lexcom formats: UM00K4 for 24 x E-DAT UM00K5 for 24 x E Keystone UM00K6 for 18 x Lexcom and 1 x fibreglass UM00K4 UM00K5 UM00K6...
  • Page 81 univers FW internal fitting system The UM00K5 and UM00K6 supports are included in the UM00M5 and UM00M6 sets. These sets contain: 2 modem holders (VZ02MM) 3 cable clips (FZ913) Schuko-type triple socket (VZ00AS) matching covers for the sockets (US00S2) and for the patch panel (US00S3) with tower overparts Steel patch panel UM00M5...
  • Page 82 univers FW internal fitting system FZ12MM/FZ12MMO/FZ12MK The Volta FZ12MM patch panels with 12 patch openings in E-DAT or Keystone format are compatible with the field distributor. FZ12MM has 6 E-DAT modules Cat.6A, 10 Gbit/s, Class E. FZ12MMO is suitable for E-DAT and has no E-DAT modules.

  • Page 83: Berker Integro Design Flow Patch Panel And Socket Holder

    univers FW internal fitting system 6.4.2 Berker Integro Design Flow patch panel and socket holder UM00K3 A special patch panel and socket combination has been designed for the German market. The UM00K3 holder has 1 opening on the left and right for Berker Integro Design Flow-type components and 10 patch openings in the centre.
  • Page 84 univers FW internal fitting system UM00K7 The UM00K7 patch is similar to UM00K3 but in the centre, it has 5 openings for Lexcom patch inserts and 1 opening for a fibreglass plug. UM00K7 UM00K8 The UM00K8 patch is similar to UM00K3 but in the centre, it has 10 openings for Keystone patch inserts.

  • Page 85: Patch Panel And Flf Socket Holder

    UM00H1 UM00H2 In the centre, the UM00H1 and H2 patch openings are compatible with HMS patch inserts WH7… HMS stands for Hager Multimedia System. WH70300200Z UM00K1 UM00K2 In the centre, the UM00K1 and K2 patch openings are compatible with Keystone patch inserts.
  • Page 86 univers FW internal fitting system On the left and right, FLF modules, type 13, size I and/or size II can be inserted. These modules are known as “Fertigapparate” in Switzerland. WH37580300D WH66549000D WH37641300D WH37620300D Technical changes reserved...

  • Page 87: Um00H0 Flf Socket Holder

    UM00H0 FLF socket holder The UM00H0 socket holder is compatible with the Swiss FLF socket system, type 13. Hager FLF double or triple sockets WH37… can be clicked into the metal plate opening. The holders can be directly screwed vertically onto vertical uprights or mounting plates.
  • Page 88 univers FW internal fitting system FLF sockets must be covered with the WH37961523Z cover to guarantee protection class II. Mounting the WH37961523Z cover for FLF sockets to guarantee protection class II. Technical changes reserved...

  • Page 89: Vz00Apz Set With Socket And Holder

    univers FW internal fitting system 6.4.5 VZ00APZ set with socket and holder The VZ00APZ set can be screwed into the FWU enclosure on a vertical upright or mounting plate. It consists of: 1 steel support with screws Berker Schuko socket with cover VZ00APZ 6.4.6 Volta VZ00AS/VZ00ASF multi-socket...

  • Page 90: Us00Sx Multimedia Covers

    univers FW internal fitting system 6.4.7 US00Sx multimedia covers Two special univers covers have been developed to cover the patch panel and the Volta triple socket: US00S1 includes both covers as a set with tower overparts. US00S2 includes the patch panel cover only with tower overparts. US00S3 includes the socket cover only with tower overparts.

  • Page 91: Um00Mx Multimedia Set

    univers FW internal fitting system 6.4.8 UM00Mx multimedia set Various UM00Mx multimedia sets have been developed for the main markets of the field distributor. They contain patch panels, covers, tower overparts and other multimedia accessories, and can be ordered with just one product code: Overview of UM00Mx multimedia set UM00M1 contains patch panel VZ12MM.

  • Page 92: Accessories For Interior Fittings

    Accessories for interior fittings Accessories for interior fittings Coding The order number code for new accessories for the univers FW series contains: the enclosure type: FWU… the number 00 (accessory): FWU00... the accessory designation: FWU00V3 and if applicable, information about the housing dimensions (height or width): FWU00V3 Accessories Designation...

  • Page 93: General Accessories In Detail

    Support the base of the enclosure to take up the weight of the wired enclosure. If the enclosure is very heavy, Hager recommends mounting a transverse batten beneath it. To do so, see also installation manual 6LE005468A supplied with the enclosure.
  • Page 94 Accessories for interior fittings Mounting hollow wall anchors Mounting the VZ405N hollow wall anchor in wall cabinets Keeping space free around the sides in the wall cavity To mount the VZ405N hollow wall anchor, a minimum distance of 32 mm must be kept free around the sides so that the hollow wall anchor can be flipped forward unhampered.

  • Page 95: Frame Plaster Compensation: Depth Adjustment Set Fz279

    Accessories for interior fittings 7.2.2 Frame plaster compensation: Depth adjustment set FZ279 The standard depth adjustment in the wall cabinet is up to 12 mm over the elongated holes in the frame. With the depth adjustment set FZ279, the frame can be moved up to 32 mm forward, increasing the distance between the device and the door or the door sash lock by up to 20 mm.

  • Page 96: Flange Vz741 For Rear Cable Entry

    Accessories for interior fittings 7.2.3 Flange VZ741 for rear cable entry The rear cable entry can be closed using the dust-tight flange VZ741. To do so, the rear cable entry in the plastic head/foot section must be fully cut out (before installing the enclosure in the wall).

  • Page 97: Cable Strain Relief Fz850F

    Accessories for interior fittings 7.2.5 Cable strain relief FZ850F At the top and bottom, the FWU enclosure contains a built-in cable strain relief mechanism for attaching conduits and cables using cable ties. As another option for attaching cables/increasing strain relief, you can also mount FZ850 cable strain relief bars.
  • Page 98 Accessories for interior fittings Mounting cable strain relief bar FZ850F The bars can be turned 180° upwards or to the side. Options for turning cable strain relief bar FZ850F The screws must be fastened with a max. torque of 1.4 Nm. Mounting the FZ850F cable strain relief bar Technical changes reserved...

  • Page 99: Cable Clips M7240 For Lateral Cable Duct

    Accessories for interior fittings 7.2.6 Cable clips M7240 for lateral cable duct 4 cable clips are supplied with every FWU enclosure for attaching cables in the side cable duct (see section 4.2.1). If more than 4 parts are required, accessory set M7240 with 10 parts can be ordered separately.

  • Page 100: Cable Cover Fwu00Cx For Lateral Cable Duct

    Accessories for interior fittings 7.2.7 Cable cover FWU00Cx for lateral cable duct With multimedia enclosures (FWUxxK…), a cable duct cover is mounted at the side next to the multimedia panel. For other enclosures, the cover can be ordered as an accessory via product code FWU00Cx. The halogen-free cover can also be clipped into place over the clips (similarly to the Tehalit LFH cable trunking system).

  • Page 101: Partitions

    Accessories for interior fittings 7.2.8 Partitions The univers FW kits can be partitioned vertically and horizontally. Enclosure with mounted partitions Horizontal partition A horizontal partition inside a 250 mm-wide field (separation) can be made using the parts UT44EN or ZZ10H. UT44EN: Screwing onto the vertical uprights This 250 mm-wide partition is screwed directly onto the vertical uprights.
  • Page 102 Accessories for interior fittings ZZ10H: Clicking into double towers UZ04A1 This 250 mm-wide partition is clicked into the double towers UZ04A1. This partition is also an accessory of the FWB surface-mounted field distributor. For installation in the flush-mounted FWU field distributor, the part must be cut off at the bottom.
  • Page 103 Accessories for interior fittings The new partitions no longer need to be screwed onto the vertical uprights. They are simply clicked in at the side beneath the vertical upright. The FWU00Vx partitions have interesting features: Cut-outs in the centre for installing double tower UZ04A1 Top/bottom pre-punches for cable entry...
  • Page 104 Accessories for interior fittings Mounting instructions: Positions for installing double towers The positions for installing double towers are shown in the following illustration using a grid of 150 mm: Positions for installing double towers Technical changes reserved...

  • Page 105: Screw Set Zz44Sf For Vertical Upright Fixing

    Accessories for interior fittings 7.2.9 Screw set ZZ44SF for vertical upright fixing If required, kits can be screwed on using the ZZ44SF accessory set. One set contains 4 screws for FWB, 4 screws for FWU and 4 counternuts. For the FWU installation, 4 counternuts are first pushed into the duct provided in the plastic head/foot section.

  • Page 106: Inspection And Maintenance

    Hager recommends performing a test at least once a year: a visual inspection (external inspection), switching operations of individual protective devices and switching devices (operation of RCD test buttons every six months), document all tests, for example, in an inspection book.

  • Page 107: Minimum Inspection/Maintenance Measures

    Inspection and maintenance System / operating Test interval Type of test Inspector equipment Enclosure, jacketing 1 year External visual inspection Electrically skilled and protective devices person Recommenda Switching operation / tion functional testing (with testing experience) RCD (earth-leakage Every six Operate test switch Ordinary person circuit breaker)
  • Page 108 Inspection and maintenance Inspections Remarks Condition of jacketing, attachment, If necessary, improve or replace housing parts, cover clean soiling, and fix the fastenings, observing the installation manuals in doing so - Repair damage with a suitable FZ791N Check for corrosion traces touch-up stick.

  • Page 109: Cleaning

    Do not use compressed air for cleaning. No wet cleaning. Remove all dirt. Hager offers a cleaning agent for plastic surfaces under order number VZ404. Technical changes reserved...

  • Page 110: Decommissioning, Disassembly And Disposal

    Decommissioning, disassembly and disposal Decommissioning, disassembly and disposal Decommissioning Decommissioning only by electrically skilled persons Switch off the system Observe the residual energies, residual voltages and residual heat Disconnect the system and supply lines from all poles and on all sides Secure against reconnection Ensure that no voltage is present Disconnect the supply line / incoming unit...

  • Page 111: 10 List Of All Product Codes

    List of all product codes 10 List of all product codes Product Product Product Product Page Page Page Page code code code code FD00P5 FWU42K1 FWU62GS FZ002F FWU00C3 FWU42K2 FWU62K FZ002F1 FWU00C4 FWU42L FWU62K1 FZ002FM FWU00C5 FWU42M2 FWU62K2 FZ002FM2 FWU00C6 FWU42S FWU62L FZ002N...
  • Page 112 List of all product codes Product Product Product Product Page Page Page Page code code code code FZ010NM FZ022NM2 FZ141N FZ181FM2 FZ010NM2 FZ022NV FZ141NM FZ181NM FZ010NV FZ022NV1 FZ141NV1 FZ181NV1 FZ010NV1 FZ023F FZ142F FZ279 FZ011F FZ023N 41, 43 FZ142FM2 FZ850F FZ011FM FZ023NV 41, 43 FZ142N...
  • Page 113 List of all product codes Product Page Product code Page code UM81U3 UZ21M6 UM81U4 UZ31M5 UM81UK UZ31M6 UM81UM3 UZ32M5 UM81UM4 UZ41M5 UN02FN UZ41M6 UN03FN UZ42M5 UN04FN UZ51M5 UN05FN UZ51M6 UN06FN UZ52M5 UN07FN UZ61M5 UN08FN UZ61M6 UN31TN UZ62M5 UN32TN VZ00APZ UN41TN VZ00AS UN42TN VZ00ASF...

  • Page 114: 11 Glossary

    Glossary 11 Glossary Degree of pollution The degree of pollution defines the ambient conditions of a switching device. If the switching device is installed in an enclosure, the ambient conditions within the enclosure apply. The degree of pollution according to EN 61439 refers to the ambient conditions that are intended for the switchgear and controlgear assembly.
  • Page 115 Glossary EN 61439 / IEC 61439 / VDE 0660-600 The EN 61439 standard series replaced the EN 60439 standard series. The EN 61439 standard series has the goal of harmonising the rules and requirements for low-voltage switching equipment combinations. The valid part of the EN 61439 standard series is always the applicable part of the standard, e.g.
  • Page 116 Glossary Protection type / IP degree of protection For each switchgear and controlgear assembly, the protection type with the IP code is specified according to IEC 60529 and verified according to EN 61439 with regard to protection against contact with active parts and preventing solid foreign bodies from entering the system, with regard to preventing water from entering the system.

  • Page 117: 12 Index

    Index 12 Index Hybrid kits • 66 About the FWU field distributor • 12 About this manual • 4 Inspection and maintenance • 106 Accessories for interior fittings • 92 Assembling the body/wall cabinet • 51 Kit pre-mounted • 62 Kits to assemble •...
  • Page 118 Index U… DIN rail • 71 UM00H0 FLF socket holder • 87 UM00M0 plastic mounting plate • 71 UM00Mx multimedia set • 91 UN0xFN vertical uprights • 70 univers FW internal fitting system • 61 US00Sx multimedia covers • 90 Used symbols and trademarks •...
