Technical Data PR000-00-513-05
Installation and User manual for the
conventional range of fire panels
2 and 4 zone panels
Contents
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Commissioning the system . . . . . . . . . . . . . . . . . . 5
Walk test facility . . . . . . . . . . . . . . . . . . . . . . . . . . 5
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Self check detectors . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Panel fire/fault indicators . . . . . . . . . . . . . . . . . . . . 9
Technical Specifications . . . . . . . . . . . . . . . . . . . . 10
Effective January 2018
Supersedes Oct 2014
Advertisement
Table of Contents
Related Manuals for Eaton FX2202CPD
Summary of Contents for Eaton FX2202CPD
-
Page 1: Table Of Contents
Effective January 2018 Technical Data PR000-00-513-05 Supersedes Oct 2014 Installation and User manual for the conventional range of fire panels 2 and 4 zone panels Contents General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Wiring . -
Page 2: General
Mount the panel, using pre drilled screw positions, to the wall . This will prevent any possible brick dust contamination of the panel internal circuitry . Fit a 20mm gland to all cable entry points in use . EATON www.eaton.com... - Page 3 (EOLM-1) . All zone circuits must be terminated with an EOLM-1, per zone) and an unlimited number of call points per zone . connected at the end of the installed zone wiring, taking care to observe the correct polarity . Figure 5. Wiring connection drawing EATON www.eaton.com...
- Page 4 Fire Relay Continuity Continuity Continuity between C between C between C and P2 and P1 and P2 Figure 7. 2 & 4 zone panel Auxiliary relay CAUTION POWER DOWN THE FIRE PANEL BEFORE YOU CHANGE ANY RELAY SETTINGS EATON www.eaton.com...
-
Page 5: Commissioning The System
If a detector or call point is not operated within the 10 minute period then the system will automatically reset and return to normal operation . The walk test facility can be terminated at any time during test by pressing the ‘reset’ button . EATON www.eaton.com... -
Page 6: User Information
Repeat this procedure to disable further zones . The internal buzzer will pulse at a slow rate and the disabled and zone disabled LEDs will remain lit . To silence the internal buzzer ⑤ Enter access code level 2, then press button • EATON www.eaton.com... -
Page 7: Self Check Detectors
LED test mode as described above . The LEDs of all detec- tors which still have a healthy connection to the panel will flash, making it easier to identify the location of the break . Follow the instructions above to cancel LED indicator mode . EATON www.eaton.com... -
Page 8: Maintenance
All systems faults will latch on panel If a vented battery is installed, visually inspect the battery and ④ battery connections . New units supplied by Eaton are supplied Enter access code level 3, then press button • with sealed batteries, and vented batteries are no longer available as original equipment . -
Page 9: Panel Fire/Fault Indicators
short Panel in test -------- System fault Panel button pressed -------- Battery open circuit/ -------- reverse polarity Battery high/low voltage Fire Evacuation EATON www.eaton.com... -
Page 10: Technical Specifications
12 x 20mm positions 4 x slots for rear cable entry Cable Type Firetuf FT120 / FP200 Cable type 2 core 1 .5mm, screened fire rated cable Compliance Compliance to Standards EN54 Part 2 CIE and Part 4 PSE, BS5839, part1 EATON www.eaton.com... - Page 11 3 .2 Standby Time 24 hour standby + 30 minute alarm EOLM-1 Specification Operating Voltage 18 .75-30 .7 Nominal Current 1 .4 *NB suffix variants are shipped without battery. Battery can be ordered separately under material code MBAT3A212 EATON www.eaton.com...
- Page 12 Eaton Industries Manufacturing GmbH Electrical Sector EMEA Route de la Longeraie 7 1110 Morges, Switzerland Eaton .eu Eaton is a registered trademark . © 2017 Eaton All Rights Reserved January 2018 All other trademarks are property Publication No . PR000-00-513-05...
