MAESTRO UTOPIA III EVO
• Accessories per speaker / Accessoires par enceinte
A
x 1
• Unpacking procedure / Procédure de déballage
1
1 - Maestro Utopia EVO 439lbs (199kg) - 4 people
required.
1 - Maestro Utopia EVO (199 kg) - 4 personnes minimum.
3
2 - Unscrew the side panel of the box and remove it.
2 - Dévissez le couvercle puis le retirer.
notice_unpacking_maestroIIIEvo.indd 1
UNPACKING/MOUNTING
DÉBALLAGE/MONTAGE MAESTRO UTOPIA III EVO
B
x 4
D
C
x 1
x 1
2
3 - Put up the box of Maestro body, being careful about
the up and down sides.
3 - Redresser la caisse du corps Maestro en
respectant le sens.
4
A
4 - Install the ramp as indicated.
Carefully pull out the loudspeaker thanks to the girth.
4 - Disposez la rampe contre la caisse. Sortir l'enceinte en
tirant sur la sangle.
E
4
X
12/09/2017 12:43:49
