ASROCK IMB-155 Settings Manual

*15G06M028001AK*
P/ N: 15G06M028001AK V1.1
IMB-155
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
1 : 2-pin UPS Module Power Input Connector
Pin1: GND
1
Pin2: DC Input
2 : ATX Power Connector
(Input +12V & +19V~+24V)
1-4: GND
2-3: DC Input
3 : SATA Power Output Connector
4 : SATA3 Connector (SATA_1)
5 : LVDS Panel Connector
PIN Signal Name PIN Signal Name
2 LCD_VCC 1 LCD_VCC
4 LDDC_CLK 3 +3.3V
6 LVDS_A_DATA0# 5 LDDC_DATA
8 GND 7 LVDS_A_DATA0
10 LVDS_A_DATA1 9 LVDS_A_DATA1#
12 LVDS_A_DATA2# 11 GND
14 GND 13 LVDS_A_DATA2
16 LVDS_A_DATA3 15 LVDS_A_DATA3#
18 LVDS_A_CLK# 17 GND
20 GND 19 LVDS_A_CLK
22 LVDS_B_DATA0 21 LVDS_B_DATA0#
24 LVDS_B_DATA1# 23 GND
26 GND 25 LVDS_B_DATA1
28 LVDS_B_DATA2 27 LVDS_B_DATA2#
30 LVDS_B_DATA3# 29 DPLVDD_EN
32 GND 31 LVDS_B_DATA3
34 LVDS_B_CLK 33 LVDS_B_CLK#
36 CON_LBKLT_EN 35 GND
38 LCD_BLT_VCC 37 CON_LBKLT_CTL
40 LCD_BLT_VCC 39 LCD_BLT_VCC
6 : BLT_PWM1
1-2: +3V Level
2-3: +5V Level
Jumpers and Headers Setting Guide
1 2
39
DC_JACK1
1
TO_UPS1 FROM_UPS1
USB 3.0
T: USB1
38
B: USB0
USB3_PWR1
1
USB 3.0
USB3_PWR2
37
T: USB3 1
B: USB2
36
LAN1
35
LAN2
34
33
32
1
VGA_H1
31
30
29 HDMI1
IMB-155
1
28
27
HD_AUDIO1
SPDIF1
1
1
26 25 24 23
7 : Backlight Volume Control (BLT_VOL1)
PIN Signal Name
1 GPIO_VOL_UP
2 GPIO_VOL_DW
3 PWRDN
1
4 LVDS1 BLUP
5 LVDS1 BLDW
6 GND
7 GND
GND +5V
1
8 : Backlight Power Connector (BLT_PWR1)
+12V GND
PIN Signal Name
1 GND
2 GND
3 BL CTL
2 1
4 BL EN
5 LCD_BLT_VCC
6 LCD_BLT_VCC
9 : Backlight Power Select
(LCD_BLT_VCC) (BKT_PWR1)
40 39
1-2: LCD_BLT_VCC: +5V
2-3: LCD_BLT_VCC: +12V
4-5: LCD_BLT_VCC: DC_IN
10 : Panel Power Selection (LCD_VCC)
(PNL_PWR1)
1-2: LVDD: +3V
2-3: LVDD: +5V
4-5: LVDD: +12V
11 : 4-Pin CPU FAN Connector (+12V)
FAN_SPEED_CONTROL
FAN_SPEED
GND
3 4
1
SATA_1
SATA_PWR1
BIOS
Chip
USB2H_0_1
USB_PWR_H1
1
1
USB_PWR_H2
USB2H_2_3
DDR3_B1 (Support DDR3L Only)
1
1
DDR3_A1 (Support DDR3L Only)
Industrial
BUZZ2
BUZZ1
1
1
1 1
LPC1
COM1
PCIE1
PWR_COM1 PWR_COM4 PWR_COM5 PWR_COM6
1 1 1 1
22 21
1
1
4
3
+12V
2
1
1
1
1
1
1 1
CPU_FAN1
PANEL1
1
CHA_FAN1
1 1
1
COM4 COM5 COM6
PWR_JP1
1
1
CLRMOS1 JGPIO_PWR1
1
1
1 1
CI2 CI1
20 19 18 17
12 : System Panel Header
13 : Printer Port / GPIO Header (LPT_GPIO1)
Printer Port:
PIN Signal Name PIN Signal Name
SLCT
26
GND PE
GND BUSY
24
GND ACK#
22
GND SPD7
20
GND SPD6
18
GND SPD5
GND SPD4
16
GND SPD3
14
SLIN# SPD2
12
SPD1
PINIT#
10
ERROR# SPD0
AFD# STB# 8
1
6
4
2
* If you want to use the printer port function, please short pin4 and pin5 on
Digital Input / Output Power Select (JGPIO_PWR1).
14 : 4-Pin Chassis FAN Connector (+12V)
1 GND
+12V
2
FAN_SPEED
3
FAN_SPEED_CONTROL
4
15 : Digital Input / Output Default Value
Setting (JGPIO_SET1)
1-2: Pull-High
2-3: Pull-Low
16 : Digital Input / Output Power Select
1-2: +12V
2-3: +5V
3-4: +5V
4-5: GND
5
6
7
8
9
10
11
12
13
14
15
16
GND
GND RESET#
GND
PWRBTN#
PLED- HDLED-
PLED+ HDLED+
1
GPIO:
NC 25 NA
GND 23 SIO_GP30
GND 21 SIO_GP31
GND 19 SIO_GP32
GND 17 SIO_GP33
GND 15 SIO_GP34
GND 13 SIO_GP35
JGPIOPWR 11 SIO_GP36
JGPIOPWR 9 SIO_GP37
SIO_GP43 7 SIO_GP40
SIO_GP44 5 SIO_GP41
SIO_GP45 3 SIO_GP42
SIO_GP46 1 SIO_GP47
