SAFETY
READ AND SAVE THESE INSTRUCTIONS
Improper handling can cause serious damage to the appliance.
WARNING:
DO NOT operate the unit with a damaged plug or loose wall outlet. If the power cord is damaged, it
must be replaced by the manufacturer or an authorized service agent.
DO NOT cover the air intake and exhaust when in use.
This appliance is not intended for use by children. Children should be supervised and should not play
on or around the appliance.
DO NOT place objects on or sit on the unit.
Always turn off and unplug the unit when cleaning or servicing.
If service is needed contact an authorized service agent.
Unplug the unit when stored or not in use.
DO NOT run the power cord under carpeting and rugs.
Use caution to prevent tripping on cord.
DO NOT use in areas where gasoline, paint or other flammable goods are stored.
Basic safety precautions should always be followed when using electrical appliances.
This appliance has been manufactured for use in domestic environments and should not be used for
other purposes.
Only use the installation kit provided to install this unit. DO NOT attempt to extend the exhaust hose or
install this unit using other methods other than that provided in this manual. Improper installation could
void any existing warranties.
DO NOT use an extension cord with this unit.

PARTS DESCRIPTION

1
1
2
2
4
(4)
1) Control Panel
(Incl. Signal Receptor)
2) Air Outlet
3) Handle
4) Casters
2
1
4
5) Air Filter
6) Back Grill
7) Exhaust Hose Connector
8) Power Supply Cord
9) Remote Control
6
6
3
(2)
2
3
3
(1)
1
12
7
7
(3)
5
3
9
9
(9)
9
9
10
10
4
4
EN
2
(5)
5
5
5
(6)
6
7
11
11
6
(11)
8
7
(7)
11
10
(10)
10
8
8
8
(8)
10) Lower Drain Plug with
10) Water Drain Cap
Plastic Cap
(Air Conditioning Mode)
11) Upper Drain Plug
(De-humidifier Mode)
12) Air inlet filter
