3.3 Explanation of Switch 10
This switch allows you to jump between Mastermodule and DMX use. If the switch is "ON",
DMX-mode is used, if it is "OFF", the Mastermodule mode will be used.
The settings at the Switch must be made before the device is turned on. Should any
changes be made while the device is on, these will only take hold once the device has been
turned off and on again. If you wish to set a new opening time, check that switch 9 is "OFF".
Before using the device, check if switch 10 is in the correct position.
Important: In Mastermodule mode, the first 8 switches assign the opening time, in DMX
mode they set the adress!
4 Overview of DMX
8
The CO²-Jet is controlled by two DMX-channels. The first channel is the one with the adress
set at the Jet istelf, using the Dip switches. This channel is used to activate the Jet. The
second DMX-channel is the one following the first. It is used to set the opening time of the
Jet.
To activate a CO²-Jet, you must first set the wanted opening time using channel 2. The
channels are set from 0-255, where value 255 indicates a fully activated lever (100%) (see
next page graphics). The opening time in milliseconds is calculated as follows:
(Lever value - 10) * 20ms = Opening time in ms
Note:
