Explo DMX Manual page 4

3.1 Explanation of Switches 1-8
Each of the eight switches has its own value (using the binary system, as shown below),
which are used if the switch is in the "ON" position. The sum of all 8 activated switches is the
opening time, or DMX adress.
3.1.1 During Mastermodule-use
Setting the opening time for external ignition.
4
Example Opening time:
An opening time of 400ms should be used. The time can be calculated by summation of the
opening times 80 + 320 = 400. These values are assigned to switches 3 (80ms) and 5
8320ms).
Therefore, to achieve an opening time of 400ms, the Switches 3 and 5 must be in the "ON"
position, and all others at the "OFF" position.
Switch Opening time (ms)
1
2
3
4
5
6
7
8
20
40
80
160
320
640
1280
2560
