- Page 1 Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 ENGLISH USERS MANUAL...
-
Page 2: General
No part of this publication may be reproduced, duplicated or distributed without the prior written permission of the manufacturer. Daub Bakery Machinery B.V. can not be held responsible for any mistakes and / or misprints in this manual. It is recommended that you keep this manual close to, or with the machine at all times. -
Page 3: Table Of Contents
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 2 USERS MANUAL Table of contents GENERAL ..............................1 TABLE OF CONTENTS ..........................2 PRODUCT INFORMATION ........................ 3 DEFINITIONS ............................ 4 Warnings ..........................4 Description of parts of the machine ..................5 Error notifications on diplay freq.converter (option).............. -
Page 4: Product Information
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 3 USERS MANUAL Product information Manufacturer: Daub Bakery Machinery B.V. Nieuwkerksedijk 10 5051 HT Goirle P.O. box 51 5050 AB Goirle The Netherlands Tel: +31 13 5308700 Fax: +31 13 5308729... -
Page 5: Definitions
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 4 USERS MANUAL Definitions Warnings The following signs warn the operator for a possible danger because of mechanical or electrical components. Figure 2.1.1 Figure 2.1.2 Figure 2.1.1 is a sticker which is used on the machine indicating the sharpness of the knives. Do not come near the knives when machine is running. -
Page 6: Description Of Parts Of The Machine
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 5 USERS MANUAL Description of parts of the machine Figure 2.2 Error notifications on diplay freq.converter (option) The display can show several faults. Check paragraph 10.2 “Frequency controller” for the codes and description. -
Page 7: Safety
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 6 USERS MANUAL Safety Safety regulations Remove plug from the power supply when cleaning and/or maintaining the machine. Only qualified or well instructed employees can do repairs of mechanical or electrical nature. Never put your hands into the infeed side Do not use the machine when certain notifications (mentioned in paragraph 2.3) appear in the display. -
Page 8: Transport And Unpacking
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 7 USERS MANUAL Transport and unpacking Transport The machine must be transported in its original packing. In the means of transport the packing must be secured against shoving. The machine should be moved with the right lift equipment. Transport damage caused by not having followed above-mentioned regulations can not be claimed. -
Page 9: Installation
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 8 USERS MANUAL Installation Placing and maintenance Only qualified employees are allowed to install the machine. The machine can only be used for its purpose: to slice bread products. Guarantee can not be claimed if changes have been made to the machine without the manufacturers permission and/or if not-original spare parts are used. -
Page 10: Carrying Off Material
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 9 USERS MANUAL Carrying off material When carrying off a complete machine, parts or only the packing, you should comply with the legal regulations. Specifications concerning the material of the parts can be asked for at the manufacturers. Correct disposal of this product This marking shown on the product or its literature indicates that it should not be disposed with other household wastes at the end of its working life. -
Page 11: Product Description
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 10 USERS MANUAL Product description Purpose of the machine The purpose of the machine is to slice bread in pieces with equally thickness. The machine is assembled from parts, wherein the parts that come in contact with the bread are made of stainless steel, if desired Teflon-coated or are made from plastics approved for use in the food industry. -
Page 12: Description Of The Control Panel
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 11 USERS MANUAL Description of the control panel Figure 6.3 Position Description START/STOP button of the machine Emergency STOP button (option) Optional button: Oil-lubrication, Continuously START button Working of the control panel Position 1 - Start button of the machine By pressing this button the machine will start. -
Page 13: Working With The Machine
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 12 USERS MANUAL Working with the machine Taking use of the machine Check if the machine is placed correctly as described in chapter 5 “Installation”. Check if it is necessary to clean the machine because of possible transport dirt. Also check if the voltage on the machine plate is in accordance with that of your main supply. -
Page 14: Maintenance
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 13 USERS MANUAL Maintenance Cleaning Always pull the plug from the socket before starting any kind of maintenance. Never clean the machine with water. The use of water will cause oxidation and electrical problems. Only qualified employees may clean the machine. -
Page 15: Instructions Changing Knives
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 14 USERS MANUAL Instructions changing knives The knives should be positioned and tensioned correctly for the best slicing results This should be done by a technician Please read procedure carefully Turn off the main switch of the machine In order to access the knives, you need to disconnect the in- and outfeed table aswell as the covers from the machine. - Page 16 Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 15 USERS MANUAL 5. Unscrew the bolts holding the rubber mountingstrips at the the top of the front knife frame. The frame will now tilt a little towards the front. 6.
-
Page 17: Options
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 16 USERS MANUAL Options Oil-lubrication of the knives When use of a breadslicer with oil lubrication the knives will be greased through the upper knife guide. In this guide a piece of felt will be sprayed with oil. Due the capillary action of the felt , the felt will saturate completely with oil. -
Page 18: 10 Fault Finding
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 17 USERS MANUAL 10 Fault finding 10.1 Troubleshooting The machine doesn’t start The plug is not in the socket. Put the plug into the socket. Check the connections in the plug. The emergency stop can by pressed. -
Page 19: 10.2 Errorcodes Frequency Controller
Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 18 USERS MANUAL 10.2 Errorcodes frequency controller The following errorcodes could appear in the display of the frequency controller. Code Content Cause Corrective Action Voltage too high when Detection circuit malfunction Consult with supplier -oV- stopped... - Page 20 Date: 30-4-2015 D / COMPACT-SLICER Table Top Version: 01 Page 19 USERS MANUAL Code Content Cause Corrective Action 1.Attempt to modify frequency 1.Adjust 13-06 1.Parameter already locked parameter while 13-06>0. 2.Adjust 11-00 2.Attempt to reverse direction when 2.Motor direction locked 11- 00=1。...
