PARTS LIST
ASSEMBLY INSTRUCTIONS
Double Deep Wine Cellar Kits
Questions?
Toll free 1-888-373-6057 or visit WineRacksAmerica.com
Thank you and CONGRATULATIONS for
purchasing this quality product. Properly
assembled, your racking will beautifully
enhance your wine collection for many
years to come. To assemble, please check
to ensure all necessary parts are included
and follow
the assembly instructions
closely.
If you have any questions or
problems please call customer service toll
free 1-888-373-6057 Monday through
Friday 7:00 am - 5:00pm MST.
Planning to stain?
For best results we recommend you
stain or finish your racking BEFORE
assembly.
The instructions pictured are for a 6 column double deep rack. Follow the same steps for
all double deep wine cellar racks, regardless of model.
PARTS LIST
END LADDER ASSEMBLIES
77 1/8"
SIDE VIEW
MIDDLE LADDER ASSEMBLIES
77 1/8"
SIDE VIEW
PARTS ARE NOT TO SCALE
Tools For Assembly:
Cordless Drill
Utility Knife
OR
Finish Nailer
Hammer
PARTS ARE NOT TO SCALE
1" WOOD SCREWS
FINISH NAILS
STANDARD COLUMN CONNECTORS
(Various Lengths)
SIDE VIEW
SCREWLESS COLUMN CONNECTORS
(Various Lengths)
SIDE VIEW
(All Models)
Screwdriver
+
Nail Setter
SMALL BAG OF
WOOD PUTTY
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wine racks America Double Deep Wine Cellar Kit
Summary of Contents for Wine racks America Double Deep Wine Cellar Kit
- Page 1 PARTS LIST PARTS ARE NOT TO SCALE ASSEMBLY INSTRUCTIONS Double Deep Wine Cellar Kits (All Models) Questions? Toll free 1-888-373-6057 or visit WineRacksAmerica.com Tools For Assembly: Thank you and CONGRATULATIONS for purchasing this quality product. Properly assembled, your racking will beautifully enhance your wine collection for many years to come.
- Page 2 PACKAGE CONTENTS * Please verify that you have the correct number of parts before proceeding. Depending on the model you purchased, your bundle should contain the following: MIDDLE STANDARD SCREWLESS 1" FINISH RACK LADDERS LADDERS CONNECTORS CONNECTORS SCREWS NAILS 10 column (6) 10 column (2) 10 column 9 column...
- Page 3 3. Insert the middle ladders and nish securing the top & bottom connectors using the 1" screws provided. 4. Attach the middle standard connectors so that the top edge of the lower connector is 26 5/8" from the bottom of the rack, and the top edge of the upper connector is 51 3/4" from the bottom of the rack. Secure the middle connectors using the 1"...
- Page 4 6. Attach the middle screwless connectors so that the top edge of the lower connector is 26 5/8" from the bottom of the rack, and the top edge of the upper connector is 51 3/4" from the bottom of the rack. Make sure the rack is flat on the floor while attaching the screwless connectors.
