Full Height Diamond bin
Assembly GUIDE
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
MIDDLE SUPPORT (x8)
23 15/16"
STANDARD CONNECTOR (x6)
24 13/16"
SCREWLESS CONNECTOR (x2)
24 13/16"
Package Contents
Package Contents
END LADDER ASSEMBLIES (x2)
77 1/8"
"X" ASSEMBLY (x3)
Questions?
888.373.6057
or visit
wineracksamerica.com
Page 1
tools for assembly
Required
Screwdriver
Suggested
Cordless Drill
WOOD SCREWS
FINISH NAILS
Hammer
WOOD PUTTY
Rubber Mallet
Wood Glue
Finish Nailer
+
Nail Setter
Advertisement
Related Manuals for Wine racks America Full Height Diamond Bin
Summary of Contents for Wine racks America Full Height Diamond Bin
- Page 1 Full Height Diamond bin Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 1 Package Contents tools for assembly Package Contents Required *Please verify that you have the correct number of parts before proceeding. Depending on the model you purchased, your bundle should contain the following: END LADDER ASSEMBLIES (x2) 77 1/8"...
- Page 2 Full Height Diamond bin Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 2 1. Find an open, flat area in which to work. Carefully remove all components from the box and remove banding with a utility knife. Check the parts list to verify package contents.
- Page 3 Full Height Diamond bin Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 3 4. Attach the middle screwless connectors so that the top edge of the connectors fit flush with the ladder support pieces on each vertical ladder. Make sure the rack is flat on the floor while attaching the screwless connectors.
- Page 4 Full Height Diamond bin Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 4 7. Insert the three X assemblies. The fit should be snug, not loose. Carefully work each corner into place until the assembly is seated all the way in. (figure 7) *DO NOT push on the center of the X If necessary you may need to lightly tap the 4 corners of the X Assembly with a rubber mallet.
- Page 5 Full Height Diamond bin Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 5 9. Attaching your rack to the wall (optional). Depending on how many bottles you store, your wine cellar rack could weigh as much as 540 lbs. To avoid tipping, attach your rack to the wall using one of the following methods.
